STARTER MOTOR ASSEMBLY для Arctic Cat DVX 400 (BLACK/CAT GREEN) [A2008DVI2AUSE] - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    3445-033 MOTOR, STARTER (INC. 2-10)
    MOTOR, STARTER (INC. 2-10)
  • 2
    3402-671 ...BRUSH TERMINAL SET
    ...BRUSH TERMINAL SET
  • 3
    3008-164 ...O-RING
    ...O-RING
  • 4
    3402-672 ...BRUSH HOLDER SET
    ...BRUSH HOLDER SET
  • 5
    3008-551 ...BRUSH SPRING
    ...BRUSH SPRING
  • 6
    3423-497 ...O-RING
    ...O-RING
  • 7
    3008-099 ...WASHER SET
    ...WASHER SET
  • 8
    3423-536 ...THROUGH-BOLT (INC. 9)
    ...THROUGH-BOLT (INC. 9)
  • 9
    3423-496 ...O-RING
    ...O-RING
  • 10
    3423-272 ...O RING, D:3, ID:24.5
    ...O RING, D:3, ID:24.5
  • 11
    3007-369 BOLT, CYLINDER HEAD COVER NO. 1
    BOLT, CYLINDER HEAD COVER NO. 1
  • 12
    3423-195 NUT, STARTER MOTOR, 6MM
    NUT, STARTER MOTOR, 6MM
