HEADLIGHT AND TAILLIGHT ASSEMBLIES для Arctic Cat DVX 400 (BLACK/CAT GREEN) [A2008DVI2AUSE] - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    0509-023 HOUSING, HEADLIGHT
    HOUSING, HEADLIGHT
  • 2
    0609-252 BULB, HEADLIGHT - LOW BEAM
    BULB, HEADLIGHT - LOW BEAM
  • 3
    0409-055 BULB, HEADLIGHT - HIGH BEAM
    BULB, HEADLIGHT - HIGH BEAM
  • 4
    0423-488 BOLT, CARRIAGE - M5X16
    BOLT, CARRIAGE - M5X16
  • 5
    0486-146 HARNESS, ADAPTER - HEADLIGHT
    HARNESS, ADAPTER - HEADLIGHT
  • 6
    1406-480 BRACKET, MOUNTING - HEADLIGHT
    BRACKET, MOUNTING - HEADLIGHT
  • 7
    0423-357 NUT, STAMPED-1/4" (SD 25001 SOH)
    NUT, STAMPED-1/4" (SD 25001 SOH)
  • 8
    0423-501 SCREW, SELF TAP-#10X1.5 TYPE25
    SCREW, SELF TAP-#10X1.5 TYPE25
  • 9
    0123-802 WASHER, FLAT .194X.50X.048
    WASHER, FLAT .194X.50X.048
  • 10
    0423-447 GROMMET, GAUGE MOUNT
    GROMMET, GAUGE MOUNT
  • 11
    0423-487 WASHER, SHOULDER
    WASHER, SHOULDER
  • 12
    0423-060 CLIP, TINERMAN
    CLIP, TINERMAN
  • 13
    8424-502 NUT, HEX-FLG M5X0.8 CL8 Z & Y
    NUT, HEX-FLG M5X0.8 CL8 Z & Y
  • 14
    0623-301 SCREW, SELF TAP-HWH 10X1/2 AB Z & Y
    SCREW, SELF TAP-HWH 10X1/2 AB Z & Y
  • 15
    8408-616 SCREW, CAP-HFH M6X1.0X16 CL8.8 Z & Y
    SCREW, CAP-HFH M6X1.0X16 CL8.8 Z & Y
  • 16
    0509-022 TAILLIGHT ASSEMBLY (INC. 17-19)
    TAILLIGHT ASSEMBLY (INC. 17-19)
  • 17
    0509-025 ...HOUSING, TAILLIGHT
    ...HOUSING, TAILLIGHT
  • 18
    0409-056 ...BULB,TAIL LIGHT-3157
    ...BULB,TAIL LIGHT-3157
  • 19
    0409-057 ...SOCKET, TAILLIGHT
    ...SOCKET, TAILLIGHT
  • 20
    1406-790 PAD, TAILLIGHT
    PAD, TAILLIGHT
  • 21
    0486-138 HARNESS, ADAPTER - TAILLIGHT
    HARNESS, ADAPTER - TAILLIGHT
