SIDE BAG для Suzuki VL1500BT L5 INTRUDER - 2015 года выпуска
-
№АртикулНазвание
-
195400-06J50 BAG ASSY, SIDE RIGHT HANDBAG ASSY, SIDE RIGHT HAND
-
245149-12C00 ...CUSHION, BRACE...CUSHION, BRACE
-
395413-06J00 ...SHIELD, HEAT NO.1...SHIELD, HEAT NO.1
-
495424-06J00 ...CUSHION, BRACE NO.2...CUSHION, BRACE NO.2
-
595439-06J00 ...CUSHION, UPPER...CUSHION, UPPER
-
695513-06J00 ...SHIELD, HEAT NO.2...SHIELD, HEAT NO.2
-
795536-06J00 ...CUSHION, LOWER...CUSHION, LOWER
-
895613-06J00 ...SHIELD, HEAT NO.3...SHIELD, HEAT NO.3
-
909320-11008 ...CUSHION...CUSHION
-
1095418-06J00 COVER, KEY CYLINDER RIGHT HANDCOVER, KEY CYLINDER RIGHT HAND
-
1195419-06J00 TRAY, SIDE BAG RIGHT HANDTRAY, SIDE BAG RIGHT HAND
-
1295500-06J40 BAG ASSY, SIDE LEFT HANDBAG ASSY, SIDE LEFT HAND
-
1345149-12C00 ...CUSHION, BRACE...CUSHION, BRACE
-
1495424-06J00 ...CUSHION, BRACE NO.2...CUSHION, BRACE NO.2
-
1595439-06J00 ...CUSHION, UPPER...CUSHION, UPPER
-
1695536-06J00 ...CUSHION, LOWER...CUSHION, LOWER
-
1709320-11008 ...CUSHION...CUSHION
-
1895518-06J00 COVER, KEY CYLINDER LEFT HANDCOVER, KEY CYLINDER LEFT HAND
-
1995519-06J00 TRAY, SIDE BAG LEFT HANDTRAY, SIDE BAG LEFT HAND
-
2095533-06J00 CUSHION, TRAYCUSHION, TRAY
-
2109280-12002 O RING (D:2.4,ID:11.8)O RING (D:2.4,ID:11.8)
-
2203541-0516A SCREWSCREW
-
2303541-0520B SCREWSCREW
-
2445289-11F00 SPRING, SIDE BAG LOCKSPRING, SIDE BAG LOCK
-
2595425-06J00 PLATE, SIDE BAG LOCKPLATE, SIDE BAG LOCK
-
2695470-06J00 BRACE, SIDE BAG RIGHT HANDBRACE, SIDE BAG RIGHT HAND
-
2795481-06J00 BRACE, SIDE BAG CENTERBRACE, SIDE BAG CENTER
-
2895482-06J00 PLATE, HEAT SHIELDPLATE, HEAT SHIELD
-
2995570-06J00 BRACE, SIDE BAG LEFT HANDBRACE, SIDE BAG LEFT HAND
-
3095700-06810 LOCK SET, SIDE BAGLOCK SET, SIDE BAG
-
3101550-0612A BOLTBOLT
-
3201550-0816B BOLTBOLT
-
3309139-06196 BOLT (6X25)BOLT (6X25)
-
3409160-06154 WASHER (6.5X20X1.6)WASHER (6.5X20X1.6)
-
3509180-06120 SPACER (6.5X11.5X12)SPACER (6.5X11.5X12)
-
3695700-41821 LOCK SET, HELMETLOCK SET, HELMET
-
3709139-06048 SCREW (6X20)SCREW (6X20)
