GASKET SET для Suzuki GSX-R750 K3 - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    11401-35850 GASKET SET (OPT)
    GASKET SET (OPT)
  • 2
    11141-35F00 ...GASKET, CYLINDER HEAD
    ...GASKET, CYLINDER HEAD
  • 3
    11173-35F00 ...GASKET, CYLINDER HEAD COVER NO.1
    ...GASKET, CYLINDER HEAD COVER NO.1
  • 4
    11178-33E00 ...GASKET, CYLINDER HEAD COVER NO.2
    ...GASKET, CYLINDER HEAD COVER NO.2
  • 5
    11182-35F00 ...COVER, 2ND AIR PASSAGE
    ...COVER, 2ND AIR PASSAGE
  • 6
    09161-11008 ...WASHER, HEAD COVER
    ...WASHER, HEAD COVER
  • 7
    11482-40F00 ...GASKET, CLUTCH COVER
    ...GASKET, CLUTCH COVER
  • 8
    11491-33E02 ...GASKET, STARTER CLUTCH COVER
    ...GASKET, STARTER CLUTCH COVER
  • 9
    09280-33004 ...O-RING, CRANKSHAFT HOLE PLUG
    ...O-RING, CRANKSHAFT HOLE PLUG
  • 10
    11492-33E00 ...GASKET, STARTER IDLE GEAR CA
    ...GASKET, STARTER IDLE GEAR CA
  • 11
    11483-35F00 ...GASKET, MAGNETO COVER
    ...GASKET, MAGNETO COVER
  • 12
    11484-35F00 ...GASKET, BREATHER COVER
    ...GASKET, BREATHER COVER
  • 13
    11489-35F00 ...GASKET, OIL PAN
    ...GASKET, OIL PAN
  • 14
    12837-35F00 ...GASKET, TENSIONER ADJUSTER
    ...GASKET, TENSIONER ADJUSTER
  • 15
    14181-02F00 ...GASKET, MUFFLER JOINT
    ...GASKET, MUFFLER JOINT
  • 16
    14181-46E00 ...GASKET, EXHAUST PIPE
    ...GASKET, EXHAUST PIPE
  • 17
    09280-08012 ...O-RING, MUFFLER (FRONT)
    ...O-RING, MUFFLER (FRONT)
  • 18
    16491-35F00 ...O-RING, OIL PUMP
    ...O-RING, OIL PUMP
  • 19
    09280-19008 ...O-RING, OIL STRAINER
    ...O-RING, OIL STRAINER
  • 20
    09280-64003 ...O-RING, OIL COOLER
    ...O-RING, OIL COOLER
  • 21
    15201-35F00 ...O-RING, FUEL PUMP
    ...O-RING, FUEL PUMP
