SIDE COVER для Suzuki DR200SL8 - 2018 года выпуска

  • №
    Артикул
    Название
  • 1-1
    47311-49J00-30H COVER, FRAME CENTER (30H - WHITE FOR 30H - WHITE)
    COVER, FRAME CENTER (30H - WHITE FOR 30H - WHITE)
  • 1-2
    47311-49J00-YU1 COVER, FRAME CENTER (YU1 - YELLOW FOR YU1 - YELLOW)
    COVER, FRAME CENTER (YU1 - YELLOW FOR YU1 - YELLOW)
  • 2
    09139-06188 SCREW (6X12)
    SCREW (6X12)
  • 3
    01550-0612A BOLT
    BOLT
  • 4
    47121-49J00-30H COVER, FRAME UPPER (RH) (30H - WHITE)
    COVER, FRAME UPPER (RH) (30H - WHITE)
  • 5
    47131-49J00 COVER, FRAME INNER (RH)
    COVER, FRAME INNER (RH)
  • 6
    47221-49J00-30H COVER, FRAME UPPER (LH) (30H - WHITE)
    COVER, FRAME UPPER (LH) (30H - WHITE)
  • 7
    09320-08018 CUSHION
    CUSHION
  • 8
    09320-08028 CUSHION
    CUSHION
  • 9
    03541-0516A SCREW
    SCREW
  • 10
    09135-08012 BOLT (8X25)
    BOLT (8X25)
  • 11
    09169-08045 WASHER
    WASHER
  • 12
    47111-49J00-30H COVER, FRAME (RH) (30H - WHITE)
    COVER, FRAME (RH) (30H - WHITE)
  • 13
    47211-49J00-30H COVER, FRAME (LH) (30H - WHITE)
    COVER, FRAME (LH) (30H - WHITE)
  • 14
    47161-08G00 CUSHION
    CUSHION
  • 15
    09320-08029 CUSHION
    CUSHION
  • 16
    09139-06169 SCREW (6X16)
    SCREW (6X16)
  • 17
    68135-49J10-BLQ TAPE, FRAME COVER (RH) (BLQ - SILVER/GRAY/GRAY/WHITE FOR 30H - WHITE)
    TAPE, FRAME COVER (RH) (BLQ - SILVER/GRAY/GRAY/WHITE FOR 30H - WHITE)
  • 18
    68145-49J10-BLQ TAPE, FRAME COVER (LH) (BLQ - SILVER/GRAY/GRAY/WHITE FOR 30H - WHITE)
    TAPE, FRAME COVER (LH) (BLQ - SILVER/GRAY/GRAY/WHITE FOR 30H - WHITE)
  • 19
    68135-49J20-BLT TAPE, FRAME COVER (RH) (BLT - YELLOW/BLUE/BLACK/WHITE/GRAY FOR YU1 - YELLOW)
    TAPE, FRAME COVER (RH) (BLT - YELLOW/BLUE/BLACK/WHITE/GRAY FOR YU1 - YELLOW)
  • 20
    68145-49J20-BLT TAPE, FRAME COVER (LH) (BLT - YELLOW/BLUE/BLACK/WHITE/GRAY FOR YU1 - YELLOW)
    TAPE, FRAME COVER (LH) (BLT - YELLOW/BLUE/BLACK/WHITE/GRAY FOR YU1 - YELLOW)
  • 21
    68171-28H00-YHG EMBLEM "SUZUKI" (YHG - GRAY)
    EMBLEM "SUZUKI" (YHG - GRAY)
