HOOD ASSEMBLY W/ WINDSHIELD для Polaris WIDETRACK LX AND EURO (S09SU4BSBE) - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    7621509 RIVET, PLASTI-LOCK
    RIVET, PLASTI-LOCK
  • 2
    5433168 WINDSHIELD, FLR, 20'' CLEAR
    WINDSHIELD, FLR, 20'' CLEAR
  • 3
    2632596 ASM-INSTRUMENT HOUSING (INCL. WARNING DECALS)
    ASM-INSTRUMENT HOUSING (INCL. WARNING DECALS)
  • 4
    5811625 FOAM, PREFILTER
    FOAM, PREFILTER
  • 5
    7517441 SCREW, .75
    SCREW, .75
  • 6
    7621334 RIVET
    RIVET
  • 7
    5430733 CUP, HOOD LATCH
    CUP, HOOD LATCH
  • 8
    5410970 RETAINER, WINDSHIELD,
    RETAINER, WINDSHIELD,
  • 9
    7621485 RIVET
    RIVET
  • 10
    7080833 CLAMP-1''UMPCO#AN735016
    CLAMP-1''UMPCO#AN735016
  • 11
    7555904 WASHER
    WASHER
  • 12
    5242893 CLIP, PIGTAIL
    CLIP, PIGTAIL
  • 13
    7661084 RIVET, 3/16(.251-.375)
    RIVET, 3/16(.251-.375)
  • 14
    7080764 CABLE, HOOD, HYB.
    CABLE, HOOD, HYB.
  • 15
    7621402 RIVET, POP
    RIVET, POP
  • 16
    7512068 SCREW
    SCREW
  • 17
    5243393 DEFLECTOR-AIR
    DEFLECTOR-AIR
  • 18
    7080886 CLIP, ROSEBUD, GRAY
    CLIP, ROSEBUD, GRAY
  • 19
    5811687 FOAM-HEADLIGHT SEAL W/PSA
    FOAM-HEADLIGHT SEAL W/PSA
