HEADLIGHT AND TAILLIGHT для Polaris WIDETRACK LX AND EURO (S09SU4BSBE) - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    1011944-067 MOUNT, WELD, H/L
    MOUNT, WELD, H/L
  • 2
    7515140 SCREW
    SCREW
  • 3
    7670057 NUT, SPEED
    NUT, SPEED
  • 4
    2433016 ASM-HEADLAMP, THREE BULB (INCL. BULBS)
    ASM-HEADLAMP, THREE BULB (INCL. BULBS)
  • 5
    4010253 BULB-HEADLIGHT, 50 WATT
    BULB-HEADLIGHT, 50 WATT
  • 6
    2870448 BULB, QUARTZ.H/L H4, 60/55W
    BULB, QUARTZ.H/L H4, 60/55W
  • 7
    5431855 LENS, LEFT HAND, CLRIGHT HAND REFLECTOR
    LENS, LEFT HAND, CLRIGHT HAND REFLECTOR
  • 7
    5431856 LENS, RIGHT HAND, CLRIGHT HAND REFLECTOR
    LENS, RIGHT HAND, CLRIGHT HAND REFLECTOR
  • 8
    7511953 SCREW
    SCREW
  • 9
    7670040 CLIP-U TYPE
    CLIP-U TYPE
  • 10
    7080887 KNOB, HEADLIGHT, ADJUST, LOCKINGB
    KNOB, HEADLIGHT, ADJUST, LOCKINGB
  • 11
    7041308 SPRING, H/LEFT HANDADJ.
    SPRING, H/LEFT HANDADJ.
  • 12
    7517746 BOLT, TEE ADJUSTER, 2.25
    BOLT, TEE ADJUSTER, 2.25
  • 13
    2410370 ASM-TAILLIGHT
    ASM-TAILLIGHT
  • 13
    4032047 BASEANDSOCKET, T/L
    BASEANDSOCKET, T/L
  • 13
    4032045 GASKET
    GASKET
  • 13
    4032046 LENS, TAILLIGHT
    LENS, TAILLIGHT
  • 13
    4032029 SCREW
    SCREW
  • 13
    4030063 BULB, T/L, EXT.DUTY
    BULB, T/L, EXT.DUTY
  • 14
    5410542 O RING
    O RING
  • 15
    7670054 NUT, PUSH-ON
    NUT, PUSH-ON
