SUSPENSION - RAIL MOUNTING для Polaris FST IQ CRUSIER (S07PY7FS) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1542270 ASM-RAIL,M10,136,BASIC, LEFT HAND [INCL. 1-3,6,7,8,11,19,23]
    ASM-RAIL,M10,136,BASIC, LEFT HAND [INCL. 1-3,6,7,8,11,19,23]
  • 1542271 ASM-RAIL,M10,136,BASIC, RIGHT HAND [INCL. 1-3,6,7,8,11,19,23]
    ASM-RAIL,M10,136,BASIC, RIGHT HAND [INCL. 1-3,6,7,8,11,19,23]
  • 1
    5435527 CAP-RAIL TIP,UHMW
    CAP-RAIL TIP,UHMW
  • 2
    7541925 NUT, NYLOK 10-24 Y
    NUT, NYLOK 10-24 Y
  • 3
    7555792 WASHER
    WASHER
  • 4
    7542324 NUT,NYLOK
    NUT,NYLOK
  • 5
    5249235 PLATE-RAIL SUPPORT,M10 STGRD
    PLATE-RAIL SUPPORT,M10 STGRD
  • 6
    7555783 WASHER,FLAT
    WASHER,FLAT
  • 7
    5412336 BUMPER-TALL
    BUMPER-TALL
  • 7
    5432946 LINER,BUMPER
    LINER,BUMPER
  • 8
    7621501 RIVET
    RIVET
  • 9
    7518519 SCR-3/8-16X4.00,SQ/CP,Y
    SCR-3/8-16X4.00,SQ/CP,Y
  • 10
    7542404 NUT
    NUT
  • 11
    5130530 BLOCK-IDLER BOLT ADJ.
    BLOCK-IDLER BOLT ADJ.
  • 12
    5631188 GUIDE-SLIDER,CAST, LEFT HAND
    GUIDE-SLIDER,CAST, LEFT HAND
  • 12
    5631189 GUIDE-SLIDER,CAST, RIGHT HAND
    GUIDE-SLIDER,CAST, RIGHT HAND
  • 13
    5436396 BLOCK-SLIDER,LONG,M-10, LEFT HAND
    BLOCK-SLIDER,LONG,M-10, LEFT HAND
  • 13
    5436397 BLOCK-SLIDER,LONG,M-10, RIGHT HAND
    BLOCK-SLIDER,LONG,M-10, RIGHT HAND
  • 14
    5245045 PLATE-COUPLER BLOCK
    PLATE-COUPLER BLOCK
  • 15
    7512310 SCREW
    SCREW
  • 16
    7556179 WASHER-SPRING,CON 5/16X.090-Y
    WASHER-SPRING,CON 5/16X.090-Y
  • 17
    7515346 SCREW
    SCREW
  • 18
    1590387-244 ASM-WHEEL,SCRL,5.62,6004,BRSLV [1 PER WHEEL]
    ASM-WHEEL,SCRL,5.62,6004,BRSLV [1 PER WHEEL]
  • 18
    7710444 RING,RETAINING [1 PER WHEEL]
    RING,RETAINING [1 PER WHEEL]
  • 18
    3514384 BEARING-.7874X1.6535X.4724,NTN
    BEARING-.7874X1.6535X.4724,NTN
  • 19
    7515317 BOLT
    BOLT
  • 20
    5631446 BLOCK-WHEEL MOUNT,6004
    BLOCK-WHEEL MOUNT,6004
  • 21
    7510504 SCREW
    SCREW
  • 22
    7661845 RIVET
    RIVET
  • 23
    7518335 BOLT-10-24X1
    BOLT-10-24X1
  • 24
    5521632 SLIDER,.45/61'',SERVICE,BASIC
    SLIDER,.45/61'',SERVICE,BASIC
  • 25
    7515199 SCREW
    SCREW
