SUSPENSION - FRONT TORQUE ARM ASSEMBLY для Polaris FST IQ CRUSIER (S07PY7FS) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    1542123-067 WELD-FTA, M-10,.803,BLK
    WELD-FTA, M-10,.803,BLK
  • 2
    7547263 NUT-3/8-24 NYLOK
    NUT-3/8-24 NYLOK
  • 3
    7515415 SCREW
    SCREW
  • 4
    7080424 FITTING, LUBRICATION
    FITTING, LUBRICATION
  • 5
    5132579 SHAFT,LOWER,PIVOT
    SHAFT,LOWER,PIVOT
  • 6
    7518261 SCR-7/16-14X2.00 HXCP-P80-GR5Y
    SCR-7/16-14X2.00 HXCP-P80-GR5Y
  • 7
    7552614 WASHER, LOCK
    WASHER, LOCK
  • 8
    7555984 WASHER,FLAT
    WASHER,FLAT
  • 9
    5135227 SHAFT-FTA,M10,UPPER
    SHAFT-FTA,M10,UPPER
  • 10
    5333905 SLEEVE,.385X.560X1.24
    SLEEVE,.385X.560X1.24
  • 11
    5220646 WASHER, DOMED
    WASHER, DOMED
  • 12
    7542324 NUT,NYLOK
    NUT,NYLOK
  • 13
    7542344 NUT,NYLOK
    NUT,NYLOK
  • 14
    5411940 STRAP-LIMITER,M-10
    STRAP-LIMITER,M-10
  • 15
    7512392 BOLT
    BOLT
  • 16
    7515316 BOLT
    BOLT
  • 17
    5630580 RETAINER,SPRING,SLOTTED
    RETAINER,SPRING,SLOTTED
  • 18
    5433503 SHIELD-SPRING,3.00
    SHIELD-SPRING,3.00
  • 19
    7041674-067 SPRING,COMP, BLACK.
    SPRING,COMP, BLACK.
  • 20
    7043207 SHOCK-F/T,ARVIN MPV
    SHOCK-F/T,ARVIN MPV
  • 21
    5210953 RETAINER,SPRING
    RETAINER,SPRING
  • 22
    5245067 RETAINER-SPRING,GAB,PLATED
    RETAINER-SPRING,GAB,PLATED
