WINDSHIELD W/ GUAGES AND HOOD RETAINER для Polaris WIDETRAK LX (S03SU4BS) - 2003 года выпуска
-
№АртикулНазвание
-
15433168 WINDSHIELD, FLR (20" CLEAR)WINDSHIELD, FLR (20" CLEAR)
-
27621509 RIVET, PLASTI LOCKRIVET, PLASTI LOCK
-
33280158 NUTNUT
-
33280156 WASHER, SPLIT LOCKWASHER, SPLIT LOCK
-
33280157 WASHER, FLATWASHER, FLAT
-
43280210 BRACKET, TACH/SPEEDOMETER (5")BRACKET, TACH/SPEEDOMETER (5")
-
52632596 INSTRUMENT HOUSING ASSY. (INCL. WARNING DECALS)INSTRUMENT HOUSING ASSY. (INCL. WARNING DECALS)
-
62460877 HARNESS JUMPER TEMP/REVHARNESS JUMPER TEMP/REV
-
74040011 INDICATOR 'TEMP' WARNINGINDICATOR 'TEMP' WARNING
-
84040019 INDICATOR 'REVERSE' WARNINGINDICATOR 'REVERSE' WARNING
-
93280186 KNOB, TRIP ODOMETER, THREADED (LEFT)KNOB, TRIP ODOMETER, THREADED (LEFT)
-
103280407 SPEEDOMETER ASSY. (5") (120 MPH) (WHITE/BLACK)SPEEDOMETER ASSY. (5") (120 MPH) (WHITE/BLACK)
-
104030015 BULB TAILLIGHT/TACH/SPEEDOMETERBULB TAILLIGHT/TACH/SPEEDOMETER
-
113280209 CUSHION, TACH/SPEEDO, RUBBERCUSHION, TACH/SPEEDO, RUBBER
-
123280341 CABLE, SPEEDO, 90 IN.CABLE, SPEEDO, 90 IN.
-
135811625 FOAM, PREFILTERFOAM, PREFILTER
-
147080138 CABLE TIECABLE TIE
-
152460909 HARNESS HEADLIGHTHARNESS HEADLIGHT
-
155811765 FOILFOIL
-
165811687 FOAM HEADLIGHT SEAL W/PSAFOAM HEADLIGHT SEAL W/PSA
-
177080886 CLIP (ROSEBUD/GRAY)CLIP (ROSEBUD/GRAY)
-
187517441 SCREW (.75)SCREW (.75)
-
197621334 RIVETRIVET
-
205430733 CUP, HOOD LATCHCUP, HOOD LATCH
-
215410970 RETAINER, WINDSHIELDRETAINER, WINDSHIELD
-
227555904 WASHERWASHER
-
235242893 CLIP, PIGTAILCLIP, PIGTAIL
-
247661084 RIVET (3/16) (.251 .375)RIVET (3/16) (.251 .375)
-
257080764 CABLE, HOOD, HYBRIDCABLE, HOOD, HYBRID
-
267621402 RIVET, POPRIVET, POP
-
277512068 SCREWSCREW
-
285243393 DEFLECTOR AIRDEFLECTOR AIR
-
297621485 RIVETRIVET
-
307080833 CLAMP (1"UMPCO#AN735016)CLAMP (1"UMPCO#AN735016)
