HOOD - FOAM/FOIL для Polaris WIDETRAK LX (S03SU4BS) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    5242858-067 SCREEN HOOD (RIGHT/BLACK)
    SCREEN HOOD (RIGHT/BLACK)
  • 2
    7511864 BOLT
    BOLT
  • 3
    7670040 CLIP U TYPE
    CLIP U TYPE
  • 4
    5243108-067 SCREEN HOOD (FRONT/UPPER/LEFT/BLACK)
    SCREEN HOOD (FRONT/UPPER/LEFT/BLACK)
  • 4
    5243109-067 SCREEN HOOD (FRONT/UPPER/RIGHT/BLACK)
    SCREEN HOOD (FRONT/UPPER/RIGHT/BLACK)
  • 5
    5243110-067 SCREEN HOOD (FRONT/LOWER/LEFT/BLACK)
    SCREEN HOOD (FRONT/LOWER/LEFT/BLACK)
  • 5
    5243111-067 SCREEN HOOD (FRONT/LOWER/RIGHT/BLACK)
    SCREEN HOOD (FRONT/LOWER/RIGHT/BLACK)
  • 6
    5811612 FOIL, HOOD (RIGHT)
    FOIL, HOOD (RIGHT)
  • 7
    5811721 FOIL HOOD (RIGHT)
    FOIL HOOD (RIGHT)
  • 8
    5811609 FOAM, HOOD (CENTER)
    FOAM, HOOD (CENTER)
  • 9
    5811703 FOIL HOOD TAB, REINFORCEMENT
    FOIL HOOD TAB, REINFORCEMENT
  • 10
    5812042 FOIL, HEAT SHIELD, HOOD (RIGHT)
    FOIL, HEAT SHIELD, HOOD (RIGHT)
  • 11
    5811621 FOIL, TAPE, W/CUTOUT
    FOIL, TAPE, W/CUTOUT
  • 12
    5811750 FOIL, LVREDGE (FRONT) (1X6.25"3M#1430)
    FOIL, LVREDGE (FRONT) (1X6.25"3M#1430)
  • 13
    7621334 RIVET
    RIVET
  • 14
    5242857-067 SCREEN HOOD (LEFT/BLACK)
    SCREEN HOOD (LEFT/BLACK)
  • 15
    5811752 FOIL, HINGE MOUNT (RIGHT) (3M#1430)
    FOIL, HINGE MOUNT (RIGHT) (3M#1430)
  • 16
    5811616 FOIL, TAPE
    FOIL, TAPE
  • 17
    5811748 FOIL, TAPE (LEFT/LOWER) (3M#427 PSA1)
    FOIL, TAPE (LEFT/LOWER) (3M#427 PSA1)
  • 18
    5811751 FOIL, HINGE MOUNT (LEFT) (3M#1430)
    FOIL, HINGE MOUNT (LEFT) (3M#1430)
  • 19
    5811749 FOIL, TAPE, LOUVER (LEFT), UP 3M#427
    FOIL, TAPE, LOUVER (LEFT), UP 3M#427
  • 20
    5811607 FOAM, HOOD (LEFT)
    FOAM, HOOD (LEFT)
