SUSPENSION - FRONT TORQUE ARM ASSEMBLY для Polaris WIDETRAK LX (S03SU4BS) - 2003 года выпуска
-
№АртикулНазвание
-
15020720 SHAFT, SPANNERSHAFT, SPANNER
-
25333012 TUBE SPACER (OUTER)TUBE SPACER (OUTER)
-
37556301 BUSHINGBUSHING
-
41543018 WHEEL, IDLERWHEEL, IDLER
-
51541044-067 ARM, FRONT TORQUE, HD, LX (BLACK)ARM, FRONT TORQUE, HD, LX (BLACK)
-
67080424 FITTING, LUBRICATIONFITTING, LUBRICATION
-
77555823 WASHERWASHER
-
85132239 SHAFT PIVOT (.750X13.235)SHAFT PIVOT (.750X13.235)
-
95630580 RETAINER, SPRING, SLOTTEDRETAINER, SPRING, SLOTTED
-
107542411 NUT, FLEXLOCNUT, FLEXLOC
-
117515433 SCREWSCREW
-
127517435 SCREWSCREW
-
137552603 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
147555893 WASHER, FLATWASHER, FLAT
-
155020909 SHAFTSHAFT
-
167041742 SHOCK, SUSPENSION (CENTER)SHOCK, SUSPENSION (CENTER)
-
175245067 RETAINER SPRING, GAB, PLATEDRETAINER SPRING, GAB, PLATED
-
187041712-067 SPRING, FRONT TRACK (BLACK)SPRING, FRONT TRACK (BLACK)
-
195430671 SHIELD SPRINGSHIELD SPRING
-
207542439 NUT, NYLOKNUT, NYLOK
-
217515438 BOLTBOLT
