OIL TANK ASSEMBLY для Polaris TRAIL RMK (S03SR5BS) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    1253352 OIL TANK W/FOIL, FC ASSY
    OIL TANK W/FOIL, FC ASSY
  • 2
    5811934 FOIL, OIL TANK
    FOIL, OIL TANK
  • 3
    7077442 DECAL, FUEL SHUT-OFF
    DECAL, FUEL SHUT-OFF
  • 4
    7512276 BOLT
    BOLT
  • 5
    7558302 WASHER, WROUGHT
    WASHER, WROUGHT
  • 6
    7670096 NUT
    NUT
  • 7
    4110134 SENSOR, OIL LEVEL
    SENSOR, OIL LEVEL
  • 8
    1240094 CAP OIL, VENTED/CUSTOM COLOR
    CAP OIL, VENTED/CUSTOM COLOR
  • 11
    7517264 SCREW
    SCREW
  • 12
    7052028 GROMMET
    GROMMET
  • 13
    7052208 FTTNG, 90 DEG. PRESS-ON
    FTTNG, 90 DEG. PRESS-ON
  • 14
    7661637 RIVET, INTERLOCK Z
    RIVET, INTERLOCK Z
  • 15
    7080884 CLIP, J
    CLIP, J
  • 16
    7517615 SCREW
    SCREW
  • 17
    5242680 BRACKET, FUEL PUMP MOUNT Z
    BRACKET, FUEL PUMP MOUNT Z
  • 18
    7542122 NUT NYLOK
    NUT NYLOK
  • 19
    5244339 BRACKET OIL TANK W/BRIDGE
    BRACKET OIL TANK W/BRIDGE
  • 20
    7080307 CLAMP, HOSE
    CLAMP, HOSE
  • 21
    8450003-1525 LINE, FUEL (1/4 ID/1525 CM.)
    LINE, FUEL (1/4 ID/1525 CM.)
  • 22
    2530009 FILTER, SMALL IN-LINE
    FILTER, SMALL IN-LINE
