CARBURETOR ASSEMBLY для Polaris 700 XC SP EDGE F/O (S02NP7CS) - 2002 года выпуска`
-
№АртикулНазвание
-
13130951 SCREWSCREW
-
23130872 CAP, TOPCAP, TOP
-
33130871 GASKETGASKET
-
43130844 SCREWSCREW
-
53130846 WASHER, PACKINGWASHER, PACKING
-
63130856 CLIPCLIP
-
73130845 RINGRING
-
83130857 PLATEPLATE
-
93130847 E-RINGE-RING
-
103130831 CAP, RUBBERCAP, RUBBER
-
113130830 HOLDER, GUIDEHOLDER, GUIDE
-
123130829 SPRINGSPRING
-
133130828 PLUNGER ASSY. (./258)PLUNGER ASSY. (./258)
-
143130940 VALVE, PISTON (1.5)VALVE, PISTON (1.5)
-
153131313 NEEDLE JET, 57 (J8-9DFH10-57)NEEDLE JET, 57 (J8-9DFH10-57)
-
163130867 PACKINGPACKING
-
173130868 E-RINGE-RING
-
183130843 PLATEPLATE
-
193130855 LEVER ASSY.LEVER ASSY.
-
193130849 LEVER ASSY.LEVER ASSY.
-
203130848 RINGRING
-
213130854 SCREWSCREW
-
223130850 SCREWSCREW
-
233130870 O-RING AIR FUNNELO-RING AIR FUNNEL
-
243131230 FUNNEL, ASSY.FUNNEL, ASSY.
-
253130825 SCREWSCREW
-
263131203 AIR JET PILOT (PAJ/.9)AIR JET PILOT (PAJ/.9)
-
273130149 JET, MAIN HEXAGON HEAD (#500)JET, MAIN HEXAGON HEAD (#500)
-
283131248 BOLT DRAINBOLT DRAIN
-
293130863 O-RINGO-RING
-
303130824 SCREWSCREW
-
313130858 FLOAT, BODYFLOAT, BODY
-
323130861 O-RINGO-RING
-
333130860 SCREWSCREW
-
343131231 FLOAT, ASSY.FLOAT, ASSY.
-
353130068 JET, PILOT (#45)JET, PILOT (#45)
-
363130769 JET, STARTER (145)JET, STARTER (145)
-
373130837 WASHERWASHER
-
383130836 SPRINGSPRING
-
393130987 ADJUSTERADJUSTER
-
403130986 CAPCAP
-
413131010 SCREW (MAG SIDE)SCREW (MAG SIDE)
-
423131009 SENSOR, ASSY. (MAG SIDE)SENSOR, ASSY. (MAG SIDE)
-
433130479 CAPCAP
-
443130835 PACKINGPACKING
-
457051020 VALVE, CHECK (90 DEG.)VALVE, CHECK (90 DEG.)
-
451253381 CARBURETOR ASSY.CARBURETOR ASSY.
