FRAME - CHASSIS для Polaris 700 RMK F/O 151 (S02NL7CS) - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    1013581-309 CHASSIS ASSY., SVC, EDGE, NATURAL
    CHASSIS ASSY., SVC, EDGE, NATURAL
  • 2
    7512275 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 3
    7670021 SPEED NUT
    SPEED NUT
  • 4
    7542122 NUT, LOCK
    NUT, LOCK
  • 5
    7555932 WASHER, NYLON
    WASHER, NYLON
  • 6
    3110078 STOP, TORQUE
    STOP, TORQUE
  • 7
    7542404 NUT
    NUT
  • 8
    1013377 WELD, TORQUE STOP, EDGE, 700/800
    WELD, TORQUE STOP, EDGE, 700/800
  • 9
    7517854 SCREW (3/8-16X1-P30-SPEC-Y)
    SCREW (3/8-16X1-P30-SPEC-Y)
  • 10
    7517632 SCREW
    SCREW
  • 11
    7621432 RIVET (3/16X.402)
    RIVET (3/16X.402)
  • 12
    5245003 BRACKET, JACKSHAFT, SHIELD
    BRACKET, JACKSHAFT, SHIELD
  • 13
    5245202 BRACKET, OIL BOTTLE, BULKHEAD
    BRACKET, OIL BOTTLE, BULKHEAD
  • 14
    5245725 BRACKET, AIR BOX, EDGE
    BRACKET, AIR BOX, EDGE
  • 15
    2202059 MOUNT KIT, TRAILING ARM (LEFT)
    MOUNT KIT, TRAILING ARM (LEFT)
  • 15
    2202060 MOUNT KIT, TRAILING ARM (RIGHT)
    MOUNT KIT, TRAILING ARM (RIGHT)
  • 16
    5521238 EXTRUSION, CLUTCHGUARD
    EXTRUSION, CLUTCHGUARD
  • 17
    5433150 STRAP, RUBBER
    STRAP, RUBBER
  • 18
    5245457 MOUNT, CONSOLE, TOE CLIP (LEFT)
    MOUNT, CONSOLE, TOE CLIP (LEFT)
  • 18
    5245458 MOUNT, CONSOLE, TOE CLIP (RIGHT)
    MOUNT, CONSOLE, TOE CLIP (RIGHT)
  • 19
    7661637 RIVET, INTERLOCK
    RIVET, INTERLOCK
  • 20
    5242741 SUPPORT, FOOTREST (LEFT)
    SUPPORT, FOOTREST (LEFT)
  • 20
    5242742 SUPPORT, FOOTREST (RIGHT)
    SUPPORT, FOOTREST (RIGHT)
  • 21
    5245288 FOOTREST (LEFT) (.080)
    FOOTREST (LEFT) (.080)
  • 21
    5242740 FOOTREST (RIGHT) (.080)
    FOOTREST (RIGHT) (.080)
  • 22
    5221583 GUARD, ADAPTER DRIVE
    GUARD, ADAPTER DRIVE
  • 23
    7080416 PLUG, HOLE
    PLUG, HOLE
  • 24
    7661639 RIVET (3/16-.214-.420)
    RIVET (3/16-.214-.420)
  • 25
    5132292 BULKHEAD, FRONT, MACH
    BULKHEAD, FRONT, MACH
