HOOD ASSEMBLY W/ WINDSHIELD для Polaris 600 TOURING (S00ST6ES) - 2000 года выпуска`
-
№АртикулНазвание
-
15433667 WINDSHIELD, GEN II (17'')WINDSHIELD, GEN II (17'')
-
27621509 RIVET, PLASTI, LOCKRIVET, PLASTI, LOCK
-
33280156 WASHER, SPLIT LOCKWASHER, SPLIT LOCK
-
33280157 WASHER, FLATWASHER, FLAT
-
33280158 NUTNUT
-
43280210 BRACKET, TACHOMETER/SPEEDOMETER (5'')BRACKET, TACHOMETER/SPEEDOMETER (5'')
-
52632079 INSTRUMENT HOUSING, MIDDLE LEVEL W/REV (INCL. WARNING DECALS)INSTRUMENT HOUSING, MIDDLE LEVEL W/REV (INCL. WARNING DECALS)
-
63280209 CUSHION, TACHOMETER/SPEEDOMETER, RUBBERCUSHION, TACHOMETER/SPEEDOMETER, RUBBER
-
73280308 TACH, 6 PULSE, W/FUEL LT (5'')TACH, 6 PULSE, W/FUEL LT (5'')
-
74030015 BULB TAILLIGHT/TACHOMETER/SPEEDOMETERBULB TAILLIGHT/TACHOMETER/SPEEDOMETER
-
83280186 KNOB, TRIP ODOMETER, THD. (LEFT)KNOB, TRIP ODOMETER, THD. (LEFT)
-
93280304 SPEEDO ASSY (5'') (120MPH) (90DEG.)SPEEDO ASSY (5'') (120MPH) (90DEG.)
-
94030015 BULB TAILLIGHT/TACHOMETER/SPEEDOMETERBULB TAILLIGHT/TACHOMETER/SPEEDOMETER
-
103280341 CABLE, SPEEDOMETER (90 IN.)CABLE, SPEEDOMETER (90 IN.)
-
113280226 FUELGAUGE, BACKLIT (2'')FUELGAUGE, BACKLIT (2'')
-
114060139 FUSEFUSE
-
123280230 CUSHION, FUELGAUGE, RUBBER (2'')CUSHION, FUELGAUGE, RUBBER (2'')
-
133280228 SPACER, BRACKET, FUELGAUGESPACER, BRACKET, FUELGAUGE
-
143280229 BRACKET, FUELGAUGE (2'')BRACKET, FUELGAUGE (2'')
-
153280231 WASHERWASHER
-
163280232 NUTNUT
-
173280233 WASHER, SPLITLOCKWASHER, SPLITLOCK
-
185811625 FOAM, PREFILTERFOAM, PREFILTER
-
197080138 STRAP PANDUITSTRAP PANDUIT
-
202460732 HARNESS, HEADLIGHT, G2 COMMONHARNESS, HEADLIGHT, G2 COMMON
-
217621334 RIVETRIVET
-
225430733 CUP, HOOD LATCHCUP, HOOD LATCH
-
237517441 SCREWSCREW
-
245410970 RETAINER, WINDSHIELDRETAINER, WINDSHIELD
-
257661084 RIVET (3/16, .251, .375)RIVET (3/16, .251, .375)
-
265242893 CLIP, PIGTAILCLIP, PIGTAIL
-
277555904 BURR, RIVETBURR, RIVET
-
287080764 CABLE, HOOD, HYBRIDCABLE, HOOD, HYBRID
-
297621402 POP RIVETPOP RIVET
-
307512068 SCREWSCREW
-
315243393 DEFLECTOR, AIRDEFLECTOR, AIR
