AIR BOX для Polaris 600 TOURING (S00ST6ES) - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    7517610 SCREW
    SCREW
  • 2
    7552604 WASHER
    WASHER
  • 3
    7547103 NUT
    NUT
  • 4
    5410344 PLUG
    PLUG
  • 5
    5411075 RETAINER, TAB
    RETAINER, TAB
  • 6
    5433072 SILENCER INTAKE W/1.5 (TOP)
    SILENCER INTAKE W/1.5 (TOP)
  • 7
    7073820 DECAL, ADJUST DRIVEN CLUTCH
    DECAL, ADJUST DRIVEN CLUTCH
  • 8
    7075351 DECAL, CAUTION, AIRBOX
    DECAL, CAUTION, AIRBOX
  • 9
    7073426 DECAL, GREASING
    DECAL, GREASING
  • 10
    5243219 MESH, WIRE, FORMED
    MESH, WIRE, FORMED
  • 11
    5811564 FOAM, AIRBOX, INTERNAL (TOP)
    FOAM, AIRBOX, INTERNAL (TOP)
  • 12
    5850134 PLATE, SILENCER INTAKE
    PLATE, SILENCER INTAKE
  • 13
    5850139 PLATE, SILENCER, INTAKE, VERT.
    PLATE, SILENCER, INTAKE, VERT.
  • 14
    5433401 SILENCER, INTAKE, DRILLED, 600 EV
    SILENCER, INTAKE, DRILLED, 600 EV
  • 15
    5411129 STRAP, TIE, DOWN
    STRAP, TIE, DOWN
  • 16
    5241691 BRACKET, SILENCER MOUNT (LOWER)
    BRACKET, SILENCER MOUNT (LOWER)
  • 17
    7661638 RIVET, INTERLOCK B
    RIVET, INTERLOCK B
  • 18
    5411423 BOOT, CARB/AIRBOX (38MM)
    BOOT, CARB/AIRBOX (38MM)
  • 19
    7052127 FITTING, HOSE
    FITTING, HOSE
  • 20
    7075359 DECAL, COOL. SYSTEM
    DECAL, COOL. SYSTEM
  • 21
    5811606 FOAM, AIRBOX, CHIMNEY, HYB.
    FOAM, AIRBOX, CHIMNEY, HYB.
