RAIL ASSEMBLY W/ IDLER WHEELS #2 для Polaris 500 XC (S00SB5AS) - 2000 года выпуска
-
№АртикулНазвание
-
17517247 SCREWSCREW
-
27552603 WASHERWASHER
-
37555923 WASHERWASHER
-
45241443 BRACKET, SHAFT SUPPORTBRACKET, SHAFT SUPPORT
-
57542411 NUT LOCKNUT LOCK
-
67555806 WASHERWASHER
-
77555893 WASHERWASHER
-
87515526 BOLTBOLT
-
97571629 WASHERWASHER
-
101594083-293 WHEEL, IDLER SCRLLD (INDY RED)WHEEL, IDLER SCRLLD (INDY RED)
-
103514012 BEARINGBEARING
-
107718407 RING, RETAININGRING, RETAINING
-
115432535 SPACER, IDLERSPACER, IDLER
-
127555918 BUSHINGBUSHING
-
131594087 WHEEL ASSY., PLAIN (6.38 O.D.)WHEEL ASSY., PLAIN (6.38 O.D.)
-
145333283 SPACER, IDLER (CENTER)SPACER, IDLER (CENTER)
-
155020744 SHAFT, IDLERSHAFT, IDLER
-
167517353 SCREWSCREW
-
175521405 SLIDER (WHITE)SLIDER (WHITE)
-
185333404 SHAFTSHAFT
-
191540982-067 ARM, PIVOT (REAR)ARM, PIVOT (REAR)
-
207080433 ZERK, FITTING THREADEDZERK, FITTING THREADED
-
215020724 SHAFT, PIVOT ARMSHAFT, PIVOT ARM
-
225020723 SHAFT, PIVOT ARMSHAFT, PIVOT ARM
-
235222839 CLIP, TRACK (OPT)CLIP, TRACK (OPT)
-
235222840 CLIP, GUIDE (OPT)CLIP, GUIDE (OPT)
-
235411379 TRACK (121''X15) (82 LUG)TRACK (121''X15) (82 LUG)
