SUSPENSION - REAR TORQUE ARM ASSEMBLY для Polaris 500 INDY (S00SB4BS) - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    7517435 BOLT
    BOLT
  • 2
    7552603 WASHER
    WASHER
  • 3
    7555893 WASHER
    WASHER
  • 4
    5131910 SHAFT, TORQUE (REAR) (UPPER)
    SHAFT, TORQUE (REAR) (UPPER)
  • 5
    1541290-067 ARM, TORQUE (BLK) (REAR)
    ARM, TORQUE (BLK) (REAR)
  • 6
    7542411 NUT LOCK
    NUT LOCK
  • 7
    7512377 BOLT
    BOLT
  • 8
    5333536 SHAFT
    SHAFT
  • 9
    7010050 BOLT, EYE
    BOLT, EYE
  • 10
    7080433 ZERK, FITTING, THREADED
    ZERK, FITTING, THREADED
  • 11
    7542324 NUT
    NUT
  • 12
    7517232 SCREW
    SCREW
  • 13
    7080394 CLIP
    CLIP
  • 14
    5432983 ROLLER, SPRING, ADJUST SQUARE (X10)
    ROLLER, SPRING, ADJUST SQUARE (X10)
  • 15
    5131911 COLLAR, BEARING LOCK
    COLLAR, BEARING LOCK
  • 16
    7512257 SCREW, SET
    SCREW, SET
  • 17
    1543023 WHEEL, CARRIER
    WHEEL, CARRIER
  • 17
    3514303 BEARING (1 PER WHEEL)
    BEARING (1 PER WHEEL)
  • 17
    7718407 RING, RETAINING (1 PER WHEEL)
    RING, RETAINING (1 PER WHEEL)
  • 18
    7555787 WASHER, REVERSE
    WASHER, REVERSE
  • 19
    7041627-067 SPRING, TORSION (LEFT) (BLK) (.347/77) (OPT.)
    SPRING, TORSION (LEFT) (BLK) (.347/77) (OPT.)
  • 19
    7041628-067 SPRING, TORSION (RIGHT) (BLK) (.347/77) (OPT.)
    SPRING, TORSION (RIGHT) (BLK) (.347/77) (OPT.)
  • 19
    7041629-067 SPRING, TORSION (LEFT) (BLK) (.359/77) (STANDARD)
    SPRING, TORSION (LEFT) (BLK) (.359/77) (STANDARD)
  • 19
    7041630-067 SPRING, TORSION (RIGHT) (BLK) (.359/77) (STANDARD)
    SPRING, TORSION (RIGHT) (BLK) (.359/77) (STANDARD)
  • 19
    7041631-067 SPRING, TORSION (LEFT) (BLK) (.375/77) (OPT.)
    SPRING, TORSION (LEFT) (BLK) (.375/77) (OPT.)
  • 19
    7041632-067 SPRING, TORSION (RIGHT) (BLK) (.375/77) (OPT.)
    SPRING, TORSION (RIGHT) (BLK) (.375/77) (OPT.)
  • 20
    5433007 SLEEVE, TORSION SPRING
    SLEEVE, TORSION SPRING
  • 21
    7555716 WASHER
    WASHER
  • 22
    5411061 STRAP, LIMITER
    STRAP, LIMITER
  • 23
    7512310 SCREW
    SCREW
  • 24
    5020561 BUSHING, PIVOT TUBE
    BUSHING, PIVOT TUBE
  • 25
    7555795 WASHER, WAVE SPRING
    WASHER, WAVE SPRING
  • 26
    5333559 SPACER
    SPACER
  • 27
    1541015-067 ROD, SHOCK
    ROD, SHOCK
  • 28
    7515472 BOLT
    BOLT
  • 29
    7041794 SHOCK, TRK, SELECT (REAR)
    SHOCK, TRK, SELECT (REAR)
  • 30
    5010422 BUSHING
    BUSHING
  • 31
    7512410 BOLT
    BOLT
