RAIL ASSEMBLY W/ IDLER WHEELS для Polaris 500 INDY (S00SB4BS) - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    7517247 SCREW
    SCREW
  • 2
    7552603 WASHER
    WASHER
  • 3
    7555806 WASHER
    WASHER
  • 4
    5241443 BRACKET, SHAFT SUPPORT
    BRACKET, SHAFT SUPPORT
  • 5
    7542411 NUT LOCK
    NUT LOCK
  • 6
    7555893 WASHER
    WASHER
  • 7
    7515526 BOLT
    BOLT
  • 8
    7571629 WASHER
    WASHER
  • 9
    1594083-293 WHEEL, IDLER, SCRLLD (INDYRED)
    WHEEL, IDLER, SCRLLD (INDYRED)
  • 10
    5432535 SPACER, IDLER
    SPACER, IDLER
  • 11
    7555918 BUSHING
    BUSHING
  • 12
    1594087 WHEEL ASSY., PLAIN (6.38 O.D.)
    WHEEL ASSY., PLAIN (6.38 O.D.)
  • 12
    3514012 BEARING
    BEARING
  • 12
    7710444 RING, RETAINING
    RING, RETAINING
  • 13
    5333285 SPACER, IDLER, LONG
    SPACER, IDLER, LONG
  • 14
    5020744 SHAFT, IDLER
    SHAFT, IDLER
  • 15
    7517353 SCREW
    SCREW
  • 16
    5521452 SLIDER (WHITE)
    SLIDER (WHITE)
  • 17
    5222839 CLIP, TRACK, CAMOPLAST
    CLIP, TRACK, CAMOPLAST
  • 17
    5222840 CLIP, GUIDE, CAMOPLAST
    CLIP, GUIDE, CAMOPLAST
  • 17
    5411168 TRACK MODULE LIGHTNING (121''X.82)
    TRACK MODULE LIGHTNING (121''X.82)
  • 18
    5020723 SHAFT, PIVOT ARM
    SHAFT, PIVOT ARM
  • 19
    5020724 SHAFT, PIVOT ARM
    SHAFT, PIVOT ARM
  • 20
    5333404 SHAFT
    SHAFT
  • 21
    1540982-067 ARM, PIVOT (REAR)
    ARM, PIVOT (REAR)
  • 22
    7080433 ZERK, FITTING, THREADED
    ZERK, FITTING, THREADED
