DUMP BOX ASSY. для Polaris SPORTSMAN 570 6X6 (SAGE BRUSH GREEN) [A18S6E57B1] - 2018 года выпуска

  • №
    Артикул
    Название
  • 1
    7515177 SCREW
    SCREW
  • 2
    7556386 WSHR-.275X.84X.075 BLACK-M
    WSHR-.275X.84X.075 BLACK-M
  • 3
    5132358 ROD, HINGE
    ROD, HINGE
  • 4
    5433388 TAILGATE
    TAILGATE
  • 5
    7517561 SCREW
    SCREW
  • 6
    5433656 LATCH
    LATCH
  • 7
    5433655 LATCH, PADDLE
    LATCH, PADDLE
  • 8
    7661644 PIN, HITCH
    PIN, HITCH
  • 9
    7556143 WASHER, RUBBER
    WASHER, RUBBER
  • 10
    5132373 SHAFT, LATCH
    SHAFT, LATCH
  • 11
    2687058-070 ASM-BACKREST, 6X6, BLACK (INCL. COVER)
    ASM-BACKREST, 6X6, BLACK (INCL. COVER)
  • 11
    2687059-070 COVERING-BACKREST, 6X6, BLACK
    COVERING-BACKREST, 6X6, BLACK
  • 12
    5243304 BRACKET, BOX LATCH
    BRACKET, BOX LATCH
  • 13
    7517938 SCREW
    SCREW
  • 14
    7081101 RING, TIE DOWN
    RING, TIE DOWN
  • 15
    5452897-070 GUARD-MUD, BOX, LEFT HAND, BLACK
    GUARD-MUD, BOX, LEFT HAND, BLACK
  • 16
    7517742 SCREW
    SCREW
  • 17
    7080881 CABLE, TAILGATE
    CABLE, TAILGATE
  • 18
    5244068-067 COVER, TAILGATE, BLACK
    COVER, TAILGATE, BLACK
  • 19
    5453029 BOX-PLASTIC, 6X6 (INCL. WARNING DECAL)
    BOX-PLASTIC, 6X6 (INCL. WARNING DECAL)
  • 20
    7079925 DECAL, REFLECTOR, RED
    DECAL, REFLECTOR, RED
  • 21
    7517686 SCREW
    SCREW
  • 22
    5452898-070 GUARD-MUD, BOX, RIGHT HAND, BLACK
    GUARD-MUD, BOX, RIGHT HAND, BLACK
  • 23
    1016881-067 SUPPORT, BOX, BLACK
    SUPPORT, BOX, BLACK
  • 24
    7518905 SCR-1/4-20X5/8, TORX, TRUSS
    SCR-1/4-20X5/8, TORX, TRUSS
  • 25
    7519045 SCR-TX TRUSS-#14X3/4, HI/LO ZBK
    SCR-TX TRUSS-#14X3/4, HI/LO ZBK
  • 26
    7518196 SCR-10-24X3/4 PH/TX/TRI-SEMS Y
    SCR-10-24X3/4 PH/TX/TRI-SEMS Y
