DRIVESHAFT - REAR для Polaris SPORTSMAN 500 DUSE (A01CH50AD) - 2001 года выпуска

  • №
    Артикул
    Название
  • 1A
    1380142 SHAFT, DRIVE BTB (REAR) (INCL. 1-8)
    SHAFT, DRIVE BTB (REAR) (INCL. 1-8)
  • 1
    1590280 CV JOINT
    CV JOINT
  • 2
    1350044 CLAMP, LARGE SHAFT BTB (REAR)
    CLAMP, LARGE SHAFT BTB (REAR)
  • 3
    1350046 GREASE, SHAFT 30G BTB (REAR)
    GREASE, SHAFT 30G BTB (REAR)
  • 4
    1350045 BOOT SHAFT BTB (REAR)
    BOOT SHAFT BTB (REAR)
  • 5
    1350043 CLAMP, SMALL SHAFT BTB (REAR)
    CLAMP, SMALL SHAFT BTB (REAR)
  • 6
    1350047 GREASE, SHAFT 50G BTB (REAR)
    GREASE, SHAFT 50G BTB (REAR)
  • 7
    1590281 PLUNGING JOINT
    PLUNGING JOINT
  • 8
    1350042 SPRING, RING
    SPRING, RING
  • 9
    2201374 BOOT, KIT (GEAR SIDE)
    BOOT, KIT (GEAR SIDE)
  • 10
    2201373 BOOT (WHEEL SIDE)
    BOOT (WHEEL SIDE)
