COOLING SYSTEM для Polaris DIESEL (A00CH46CA) - 2000 года выпуска`
-
№АртикулНазвание
-
17080696 CLAMP, HOSE (1.25) WORM DRIVECLAMP, HOSE (1.25) WORM DRIVE
-
21240044 CAP, PRESSURE (13 PSI)CAP, PRESSURE (13 PSI)
-
35433364 FILLER, REMOTE COOLANTFILLER, REMOTE COOLANT
-
45243505-067 BRACKET, REMOTE COOLANT FILLBRACKET, REMOTE COOLANT FILL
-
57661638 RIVET, INTERLOCKRIVET, INTERLOCK
-
65433707 FLEX GUARDFLEX GUARD
-
75411783 HOSE, UPPER ENGINEHOSE, UPPER ENGINE
-
87080827 CLAMP, ROTO SPRING 1''CLAMP, ROTO SPRING 1''
-
97512024 SCREWSCREW
-
105411632 HOSE, FILLER NECKHOSE, FILLER NECK
-
117080826 CLAMP, ROTO CLIPCLAMP, ROTO CLIP
-
127517659 SCREWSCREW
-
132410123 FAN AND MOTOR ASSY., SPALFAN AND MOTOR ASSY., SPAL
-
147670111 CLIPCLIP
-
157080492 STRAP, WEATHER RESISTANT (BLACK)STRAP, WEATHER RESISTANT (BLACK)
-
167547069 NUTSERT, HEXNUTSERT, HEX
-
173110032 MOUNT, RUBBERMOUNT, RUBBER
-
185020572 SPACER, MOUNTSPACER, MOUNT
-
195433059 SHROUD, FANSHROUD, FAN
-
207080890 STRAP, PANDUIT PANEL TIESTRAP, PANDUIT PANEL TIE
-
214010161 SENSOR, THERMAL/HARNESSSENSOR, THERMAL/HARNESS
-
221240045 RADIATORRADIATOR
-
237552605 WASHERWASHER
-
247512113 SCREWSCREW
-
255433317 COVER, RADIATOR W/MESHCOVER, RADIATOR W/MESH
-
265410607 O-RINGO-RING
-
277052244 VALVE, PLASTIC DRAINVALVE, PLASTIC DRAIN
-
285410584 BUSHING, MOUNT (LOW RED)BUSHING, MOUNT (LOW RED)
-
295243503-067 BRACKET, RADIATOR LOWER (BLACK)BRACKET, RADIATOR LOWER (BLACK)
-
307512232 BOLTBOLT
-
317080138 STRAP, PANDUITSTRAP, PANDUIT
-
325411782 HOSE, LOWER ENGINEHOSE, LOWER ENGINE
-
335521550 PLASTIC, HOSEGUARD 18''PLASTIC, HOSEGUARD 18''
-
347080807 CLAMP, HOSECLAMP, HOSE
-
357517386 SCREWSCREW
-
365430743 CAP, OVERFLOWCAP, OVERFLOW
-
375810279 GASKETGASKET
-
385433774 CAP, PLUG FLEX TEMP (GREEN)CAP, PLUG FLEX TEMP (GREEN)
-
395432855 TANK, SURGE DIESELTANK, SURGE DIESEL
-
408450003-1525 FUEL LINE (1/4 ID 1525 CM.)FUEL LINE (1/4 ID 1525 CM.)
-
417052065 FITTING, 90 DEGREEFITTING, 90 DEGREE
-
427512084 SCREWSCREW
