GEARCASE - CASE AND SNORKLE для Polaris DIESEL (A00CH46CA) - 2000 года выпуска
-
№АртикулНазвание
-
13233256 SEALSEAL
-
23233636 DECAL, SWITCHDECAL, SWITCH
-
33233248 SEAL, TRIPLE LIPSEAL, TRIPLE LIP
-
43233252 SCREWSCREW
-
53233716 GEARCASE (LEFT)GEARCASE (LEFT)
-
63233247 PIN, DOWELPIN, DOWEL
-
73233037 VENTVENT
-
83233475 DIPSTICKDIPSTICK
-
93233749 SCREWSCREW
-
103233617 SWITCH, GEAR INICATION 2 PISTONSSWITCH, GEAR INICATION 2 PISTONS
-
113233635 SWITCH, GEAR INICATION 3 PISTONSSWITCH, GEAR INICATION 3 PISTONS
-
123233442 BOLTBOLT
-
143233352 WASHERWASHER
-
153233476 GEAR, SNORKEL (31 TEETH)GEAR, SNORKEL (31 TEETH)
-
173233446 SHAFT, SNORKELSHAFT, SNORKEL
-
183233302 O-RINGO-RING
-
193233750 TUBE, SNORKELTUBE, SNORKEL
-
203233305 BEARING, BALLBEARING, BALL
-
213233353 SPACER (1.180X.995X.010) (OPT)SPACER (1.180X.995X.010) (OPT)
-
213233354 SPACER (1.180X.995X.025) (OPT)SPACER (1.180X.995X.025) (OPT)
-
213233355 SPACER (1.180X.995X.040) (OPT)SPACER (1.180X.995X.040) (OPT)
-
213233356 SPACER (1.180X.995X.005) (OPT)SPACER (1.180X.995X.005) (OPT)
-
213233357 SPACER (1.180X.995X.008) (OPT) SEE NOTE:SPACER (1.180X.995X.008) (OPT) SEE NOTE:
-
223233306 RING, RETAININGRING, RETAINING
-
233233444 BOLT, LOCK SNORKEL GEARBOLT, LOCK SNORKEL GEAR
-
243233351 BOLTBOLT
-
253233293 SEALSEAL
-
263233292 BUSHINGBUSHING
-
273233291 NUT, FLEX LOCKNUT, FLEX LOCK
-
283233294 PLATE, COVERPLATE, COVER
-
293233295 WASHER, LOCKWASHER, LOCK
-
303233296 SCREWSCREW
-
313233253 PLUG, HEX FLANGEPLUG, HEX FLANGE
-
323233254 PLUG, WASHERPLUG, WASHER
-
333233748 GEARCASE (RIGHT)GEARCASE (RIGHT)
-
343233026 SCREWSCREW
