OIL TANK для Polaris DIESEL (A00CH46CA) - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    7511848 SCREW, SEMS
    SCREW, SEMS
  • 2
    5211523 PLATE, VENT OIL TANK
    PLATE, VENT OIL TANK
  • 3
    5830053 GASKET, OIL RESERVOIR
    GASKET, OIL RESERVOIR
  • 4
    7052163 FITTING
    FITTING
  • 5
    5411668 BREATHER, LINE-112 CM SLIT (OPT)
    BREATHER, LINE-112 CM SLIT (OPT)
  • 6
    5432289 DIPSTICK
    DIPSTICK
  • 7
    5410889 O-RING
    O-RING
  • 8
    7555896 WASHER, COPPER (14MM.)
    WASHER, COPPER (14MM.)
  • 9
    7052109 TUBE, BANJO RETURN
    TUBE, BANJO RETURN
  • 10
    7517102 BOLT
    BOLT
  • 11
    7052133 TUBE, BANJO INTAKE
    TUBE, BANJO INTAKE
  • 12
    2530020 SCREEN, OIL FILTER BANJO
    SCREEN, OIL FILTER BANJO
  • 13
    5131255 TANK, OIL (RIGHT)
    TANK, OIL (RIGHT)
  • 14
    7542122 NUT, LOCK
    NUT, LOCK
  • 15
    5411042 GROMMET
    GROMMET
  • 16
    5410828 GROMMET, MOUNTING RESERVOIR
    GROMMET, MOUNTING RESERVOIR
  • 17
    5333204 BUSHING, MOUNTING
    BUSHING, MOUNTING
  • 18
    7558301 WASHER
    WASHER
  • 19
    7512130 BOLT
    BOLT
  • 20
    7051524 PLUG, MAG.12 M.
    PLUG, MAG.12 M.
  • 21
    5850135 WASHER
    WASHER
  • 22
    7515158 SCREW
    SCREW
  • 23
    5131785 TANK, OIL (LEFT)
    TANK, OIL (LEFT)
