INSTRUMENT PANEL ASSEMBLY для Mercruiser - 190 GM 283 V-8 1963-1964 1564539 THRU 1730903

  • №
    Артикул
    Название
  • 34095A3 INSTRUMENT PANEL ASSEMBLY, COMPLETE
    INSTRUMENT PANEL ASSEMBLY, COMPLETE
  • 34095A7 INSTRUMENT PANEL ASSEMBLY, COMPLETE
    INSTRUMENT PANEL ASSEMBLY, COMPLETE
  • 1
    34102 PANEL, INSTRUMENT
    PANEL, INSTRUMENT
  • 2
    32829 OIL PRESSURE GAUGE ASSEMBLY
    OIL PRESSURE GAUGE ASSEMBLY
  • 2
    59056A1 oil pressure GAUGE ASSEMBLY
    oil pressure GAUGE ASSEMBLY
  • 3
    12-33110 WASHER, FIBER-OIL PRESSURE
    WASHER, FIBER-OIL PRESSURE
  • 4
    32826 CLAMP
    CLAMP
  • 5
    12-20878 WASHER, OIL PRESSURE GAUGE TERMINAL (#10)
    WASHER, OIL PRESSURE GAUGE TERMINAL (#10)
  • 6
    11-68219 NUT OIL PRESSURE GAUGE TERMINAL (10-32)
    NUT OIL PRESSURE GAUGE TERMINAL (10-32)
  • 7
    12-20192 WASHER OIL PRESSURE GUAGE TERMINAL (#8)
    WASHER OIL PRESSURE GUAGE TERMINAL (#8)
  • 8
    11-26419 NUT, OIL PRESSURE GAUGE TERMINAL (8-32)
    NUT, OIL PRESSURE GAUGE TERMINAL (8-32)
  • 9
    54212A9 SWITCH, IGNITION-- INSTRUMENT PANEL (WITH KEY #30431)
    SWITCH, IGNITION-- INSTRUMENT PANEL (WITH KEY #30431)
  • 10
    32870 JUMPER WIRE, IGNITION SWITCH TO OIL PRESSURE GUAGE (WHITE - 2 1/4")
    JUMPER WIRE, IGNITION SWITCH TO OIL PRESSURE GUAGE (WHITE - 2 1/4")
  • 11
    34093 PLATE IGNITION SWITCH
    PLATE IGNITION SWITCH
  • 12
    32861 BEZEL, IGNITION SWITCH TO INSTRUMENT PANEL
    BEZEL, IGNITION SWITCH TO INSTRUMENT PANEL
  • 13
    19-32863 BUTTON, PLUG-- INSTRUMENT PANEL (LARGE)
    BUTTON, PLUG-- INSTRUMENT PANEL (LARGE)
  • 14
    19-32862 BUTTOM, PLUG INSTRUMENT PANEL (SMALL)
    BUTTOM, PLUG INSTRUMENT PANEL (SMALL)
  • 15
    37-32851 DECAL, INSTRUMENT PANEL
    DECAL, INSTRUMENT PANEL
  • 16
    10-32866 SCREW, INSTRUMENT PANEL TO DASH BOARD (2")
    SCREW, INSTRUMENT PANEL TO DASH BOARD (2")
  • 17
    12-33110 WASHER FIBER INSTRUMENT PANEL SCREW
    WASHER FIBER INSTRUMENT PANEL SCREW
  • 18
    12-20878 WASHER INSTRUMENT PANEL SCREW
    WASHER INSTRUMENT PANEL SCREW
  • 19
    11-8267086 NUT INSTRUMENT PANEL SCREW
    NUT INSTRUMENT PANEL SCREW
  • 20
    79-73675A1 TACHOMETER ASSEMBLY
    TACHOMETER ASSEMBLY
  • 21
    12-20878 WASHER TACHOMETER TERMINAL (#10)
    WASHER TACHOMETER TERMINAL (#10)
  • 22
    11-68219 NUT, TACHOMETER TERMINAL (10-32)
    NUT, TACHOMETER TERMINAL (10-32)
  • 23
    32865 SOCKET LIGHT BULB-- INSTRUMENT PANEL
    SOCKET LIGHT BULB-- INSTRUMENT PANEL
  • 24
    88-67920 LIGHT BULB INSTRUMENT PANEL SOCKET
    LIGHT BULB INSTRUMENT PANEL SOCKET
  • 25
    49917A4 SOCKET LIGHT BULB TACHOMETER
    SOCKET LIGHT BULB TACHOMETER
  • 26
    88-67920 LIGHT BULB TACHOMETER SOCKET
    LIGHT BULB TACHOMETER SOCKET
  • 27
    65639A1 AMMETER GAUGE ASSEMBLY
    AMMETER GAUGE ASSEMBLY
  • 28
    12-33110 WASHER
    WASHER
  • 29
    12-20878 WASHER, AMMETER GAUGE TERMINAL (#10)
    WASHER, AMMETER GAUGE TERMINAL (#10)
  • 30
    11-68219 NUT AMMETER GAUGE TERMINAL (10-32)
    NUT AMMETER GAUGE TERMINAL (10-32)
  • 31
    34096 JUMPER WIRE IGNITION SWITCH TO AMMETER GAUGE (RED/WHITE 7 3/4)
    JUMPER WIRE IGNITION SWITCH TO AMMETER GAUGE (RED/WHITE 7 3/4)
  • 32
    32827 WATER TEMPERATURE GAUGE ASSEMBLY
    WATER TEMPERATURE GAUGE ASSEMBLY
  • 32
    59054A1 WATER TEMPERATURE GAUGE ASSEMBLY
    WATER TEMPERATURE GAUGE ASSEMBLY
  • 33
    12-33110 WASHER FIBER WATER TEMPERATURE GAUGE TERMINAL
    WASHER FIBER WATER TEMPERATURE GAUGE TERMINAL
  • 34
    32826 CLAMP WATER TEMPERATURE GUAGE
    CLAMP WATER TEMPERATURE GUAGE
  • 35
    12-20878 WASHER WATER TEMPERATURE GAUGE TERMINAL (#10)
    WASHER WATER TEMPERATURE GAUGE TERMINAL (#10)
  • 36
    11-68219 NUT, WATER TEMPERATURE GAUGE TERMINAL (10-32)
    NUT, WATER TEMPERATURE GAUGE TERMINAL (10-32)
  • 37
    12-20192 WASHER WATER TEMPERATURE GUAGE TERMINAL (#8)
    WASHER WATER TEMPERATURE GUAGE TERMINAL (#8)
  • 38
    11-26419 NUT WATER TEMPERATURE GAUGE TERMINAL (8-32)
    NUT WATER TEMPERATURE GAUGE TERMINAL (8-32)
  • 39
    32871 JUMPER WIRE WATER GAUGE TO OIL GAUGE (WHITE - 8 3/4")
    JUMPER WIRE WATER GAUGE TO OIL GAUGE (WHITE - 8 3/4")
  • 40
    32872 JUMPER WIRE IGNITION SWITCH TO REMOTE CONTROL (YELLOW 6 3/8)
    JUMPER WIRE IGNITION SWITCH TO REMOTE CONTROL (YELLOW 6 3/8)
  • 41
    33865 BINDER WIRING HARNESS AND JUMPER WIRES
    BINDER WIRING HARNESS AND JUMPER WIRES
  • 42
    10-24231 SCREW JUMPER WIRE TO REMOTE CONTROL SWITCH WIRE
    SCREW JUMPER WIRE TO REMOTE CONTROL SWITCH WIRE
  • 43
    11-68219 NUT JUMPER WIRE SCREW
    NUT JUMPER WIRE SCREW
  • 44
    85-623594 SLEEVE INSTRUMENT PANEL JUMPER WIRE
    SLEEVE INSTRUMENT PANEL JUMPER WIRE
  • 45
    22924 TERMINAL INSTRUMENT PANEL JUMPER WIRE (#10)
    TERMINAL INSTRUMENT PANEL JUMPER WIRE (#10)
  • 46
    33824 BRACKET WIRING HARNESS MOUNTING
    BRACKET WIRING HARNESS MOUNTING
  • 47
    34097 FUSE BLOCK INSTRUMENT PANEL
    FUSE BLOCK INSTRUMENT PANEL
  • 48
    10-34123 SCREW FUSE BLOCK TO MOUNTING BRACKET
    SCREW FUSE BLOCK TO MOUNTING BRACKET
  • 49
    13-26994 LOCKWASHER FUSE BLOCK SCREW
    LOCKWASHER FUSE BLOCK SCREW
  • 50
    11-21270 NUT FUSE BLOCK SCREW
    NUT FUSE BLOCK SCREW
  • 51
    34092 JUMPER WIRE FUSE BLOCK TO AMMETER GAUGE (RED/WHITE 6 1/2)
    JUMPER WIRE FUSE BLOCK TO AMMETER GAUGE (RED/WHITE 6 1/2)
  • 52
    54-23567 CLAMP WIRING HARNESS TO MOUNTING BRACKET (9/16)
    CLAMP WIRING HARNESS TO MOUNTING BRACKET (9/16)
  • 53
    10-29762 SCREW WIRING HARNESS CLAMP MOUNTING TO BRACKET
    SCREW WIRING HARNESS CLAMP MOUNTING TO BRACKET
  • 54
    8M0084613 "D" WASHER WIRING HARNESS CLAMP SCREW
    "D" WASHER WIRING HARNESS CLAMP SCREW
  • 55
    34104 WIRING HARNESS
    WIRING HARNESS
  • 56
    54-23567 CLAMP WIRING HARNESS TO BOAT
    CLAMP WIRING HARNESS TO BOAT
  • 57
    10-35401 SCREW WOOD WIRING HARNESS CLAMP TO BOAT
    SCREW WOOD WIRING HARNESS CLAMP TO BOAT
  • 58
    8M0084613 "D"WASHER WIRING HARNESS CLAMP SCREW
    "D"WASHER WIRING HARNESS CLAMP SCREW
  • 59
    32790 TERMINAL BLOCK WIRING HARNESS LEAD
    TERMINAL BLOCK WIRING HARNESS LEAD
  • 60
    10-28739 SCREW TERMINAL BLOCK
    SCREW TERMINAL BLOCK
  • 61
    10-20644 SCREW TERMINAL BLOCK TO BOAT
    SCREW TERMINAL BLOCK TO BOAT
  • 62
    11-68219 NUT TERMINAL BLOCK TO BOAT SCREW
    NUT TERMINAL BLOCK TO BOAT SCREW
  • 63
    10-35401 SCREW WOOD TERMINAL BLOCK TO BOAT
    SCREW WOOD TERMINAL BLOCK TO BOAT
