CARBURETOR ASSEMBLY ( AIR HORN AND CHOKE ASSEMBLY) для Mercruiser - 190 GM 283 V-8 1963-1964 1564539 THRU 1730903
-
№АртикулНазвание
-
1339-2249 CARBURETOR ASSEMBLY, COMPLETE (SEE NOTE BELOW)CARBURETOR ASSEMBLY, COMPLETE (SEE NOTE BELOW)
-
11339-2249 FLOAT BOWL ASSEMBLYFLOAT BOWL ASSEMBLY
-
21397-2255 FLOAT ASSEMBLYFLOAT ASSEMBLY
-
317-33555 PIN HINGE - FLOAT TO AIR HORNPIN HINGE - FLOAT TO AIR HORN
-
424-33571 SPRING, TIRSION - FLOATSPRING, TIRSION - FLOAT
-
590-8M0143356 INLET NEEDLE AND SEAT ASSEMBLYINLET NEEDLE AND SEAT ASSEMBLY
-
690-8M0143356 GASKET, INLET NEEDLE AND SEATGASKET, INLET NEEDLE AND SEAT
-
790-8M0143356 STRAINER, INLET NEEDLE AND SEATSTRAINER, INLET NEEDLE AND SEAT
-
81397-2116 CHOKE HOUSING ASSEMBLY, FLOAT BOWLCHOKE HOUSING ASSEMBLY, FLOAT BOWL
-
990-8M0143356 GASKET, CHOKE HOUSINGGASKET, CHOKE HOUSING
-
101397-2050 PLUG, BALL - CHOKE HOUSINGPLUG, BALL - CHOKE HOUSING
-
1119-33041 WELCH PLUG, CHOKE HOUSINGWELCH PLUG, CHOKE HOUSING
-
1210-33053 SCREW, CHOKE HOUSING TO FLOAT BOWLSCREW, CHOKE HOUSING TO FLOAT BOWL
-
131397-2115 LEVER ASSEMBLY, CHOKE PISTONLEVER ASSEMBLY, CHOKE PISTON
-
141397-2059 CHOKE PISTON, CHOKE HOUSINGCHOKE PISTON, CHOKE HOUSING
-
1517-33049 PIN, CHOKE PISTON TO CHOKE PISTON LEVERPIN, CHOKE PISTON TO CHOKE PISTON LEVER
-
1610-33056 SCREW, CHOKE PISTON LEVER TO CHOKE HOUSINGSCREW, CHOKE PISTON LEVER TO CHOKE HOUSING
-
171397-2110 PLATE, BAFFLE - CHOKE HOUSINGPLATE, BAFFLE - CHOKE HOUSING
-
1890-8M0143356 GASKET, STAT COVER AND COILGASKET, STAT COVER AND COIL
-
191397-2125 STAT COVER AND COIL ASSEMBLYSTAT COVER AND COIL ASSEMBLY
-
2010-33047 SCREW, STAT COVER AND COIL TO CHOKE HOUSINGSCREW, STAT COVER AND COIL TO CHOKE HOUSING
-
2154-33036 RETAINER, STAT COVER AND COIL TO CHOKE HOUSING SCREWRETAINER, STAT COVER AND COIL TO CHOKE HOUSING SCREW
-
221397-2135 AIR HORN ASSEMBLYAIR HORN ASSEMBLY
-
2390-8M0143356 GASKET, AIR HORNGASKET, AIR HORN
-
2410-33554 SCREW, SIR HORN TO FLOAT BOWL (SHORT)SCREW, SIR HORN TO FLOAT BOWL (SHORT)
-
2410-34370 SCREW, AIR HORN TO FLOAT BOWL (LONG)SCREW, AIR HORN TO FLOAT BOWL (LONG)
-
2413-26996 LOCKWASHER, AIR HORN TO FLOAT BOWL SCREWLOCKWASHER, AIR HORN TO FLOAT BOWL SCREW
-
2590-8M0143356 FILTER, AIR HORN NUTFILTER, AIR HORN NUT
-
2690-8M0143356 GASKET, AIR HORN FILTER NUTGASKET, AIR HORN FILTER NUT
-
2711-33561 NUT, FILTER - AIR HORNNUT, FILTER - AIR HORN
-
2890-8M0143356 BOOT, FLOAT BOWL PUMPBOOT, FLOAT BOWL PUMP
-
291397-2254 PUMP SHAFT AND LEVER ASSEMBLY, FLOAT BOWLPUMP SHAFT AND LEVER ASSEMBLY, FLOAT BOWL
-
3090-8M0143356 CLIP, PUMP SHAFT LEVERCLIP, PUMP SHAFT LEVER
-
311397-2267 ROD, PUMPROD, PUMP
-
3290-8M0143356 CLIP RETAINER - PUMP RODCLIP RETAINER - PUMP ROD
-
331397-2265 ROD, CHOKEROD, CHOKE
-
3490-8M0143356 CLIP, CHOKE RODCLIP, CHOKE ROD
-
351397-2111 CHOKE SHAFT ASSEMBLYCHOKE SHAFT ASSEMBLY
-
361397-2112 CHOKE SHAFT ASSEMBLY, INTERMEDIATECHOKE SHAFT ASSEMBLY, INTERMEDIATE
-
371397-2264 ROD, CHOKE SHAFTROD, CHOKE SHAFT
-
3890-8M0143356 PIN, HAIR - CHOKE SHAFT RODPIN, HAIR - CHOKE SHAFT ROD
-
391397-2104 VALVE, CHOKE - CHOKE SHAFTVALVE, CHOKE - CHOKE SHAFT
-
4010-33045 SCREW, CHOKE VALVE TO CHOKE SHAFTSCREW, CHOKE VALVE TO CHOKE SHAFT
-
411397-2113 CHOKE LEVER AND COLLAR ASSEMBLY, CHOKE SHAFTCHOKE LEVER AND COLLAR ASSEMBLY, CHOKE SHAFT
-
421397-2105 LEVER, TRIP - CHOKE SHAFTLEVER, TRIP - CHOKE SHAFT
-
4310-33056 SCREWW, TRIP LEVER TO CHOKE SHAFTSCREWW, TRIP LEVER TO CHOKE SHAFT
