SHIFT ACTUATOR ASSEMBLY, COMPLETE (STERN DRIVE) для Mercruiser - 255 MIE FORD 351 V-8 1973-1974 3258728 THRU 4178299

  • №
    Артикул
    Название
  • 1
    69392A4 SHIFT ACTUATOR ASSEMBLY, COMPLETE (SEE NOTE BELOW)
    SHIFT ACTUATOR ASSEMBLY, COMPLETE (SEE NOTE BELOW)
  • 2
    392-4949 ARMATURE
    ARMATURE
  • 3
    392-4960 SPRING SET, BRUSH
    SPRING SET, BRUSH
  • 4
    392-4955 HEAD ASSEMBLY, COMMUTATOR END
    HEAD ASSEMBLY, COMMUTATOR END
  • 5
    392-4956 BRUSH SET
    BRUSH SET
  • 6
    392-4962 THRU BOLT
    THRU BOLT
  • 7
    392-4950 FIELD COIL ASSEMBLY
    FIELD COIL ASSEMBLY
  • 8
    392-4951 CRANK ARM ASSEMBLY
    CRANK ARM ASSEMBLY
  • 9
    392-4957 HEAD ASSEMBLY, DRIVE END
    HEAD ASSEMBLY, DRIVE END
  • 10
    392-4959 SCREW AND DISC PACKAGE
    SCREW AND DISC PACKAGE
  • 11
    392-4952 GEAR AND GASKET PACKAGE
    GEAR AND GASKET PACKAGE
  • 12
    392-4953 GASKET, COVER
    GASKET, COVER
  • 13
    392-4958 PLATE,CAM
    PLATE,CAM
  • 14
    11-20890 NUT, CRANK ARM
    NUT, CRANK ARM
  • 15
    10-47220 SCREW, COVER ATTACHING(3/8")
    SCREW, COVER ATTACHING(3/8")
  • 16
    66401A1 HARNESS ASSEMBLY (3WIRE LEAD)
    HARNESS ASSEMBLY (3WIRE LEAD)
  • 17
    84-60871A5 >GROUND WIRE ASSEMBLY
    >GROUND WIRE ASSEMBLY
