OIL PAN, OIL PUMP AND CRANKCASE COVER для Mercruiser - 140 GM 181 I/L4 1972-1978 3332138 THRU 5157668

  • №
    Артикул
    Название
  • 32
    861942T1 GAUGE ASSEMBLY, OIL LEVEL (DIP STICK)
    GAUGE ASSEMBLY, OIL LEVEL (DIP STICK)
  • 33
    87717A2 TUBE, OIL LEVEL GUAGE
    TUBE, OIL LEVEL GUAGE
  • 34
    39332A1 COVER ASSEMBLY, PUSH ROD
    COVER ASSEMBLY, PUSH ROD
  • 35
    10-35765A1 SCREW, PUSH ROD TO CYLINDER BLOCK
    SCREW, PUSH ROD TO CYLINDER BLOCK
  • 36
    27-34208 GASKET, PUSH ROD COVER
    GASKET, PUSH ROD COVER
  • 37
    54-53883 CLIP, WIRING HARNESS TO PUSH ROD COVER
    SERIAL 03332138-03462607
    CLIP, WIRING HARNESS TO PUSH ROD COVER
    SERIAL 03332138-03462607
  • 38
    10-62568 SCREW, WIRING HARNESS CLIP ATTACHED
    SERIAL 03332138-03462607
    SCREW, WIRING HARNESS CLIP ATTACHED
    SERIAL 03332138-03462607
  • 39
    12-20583 WASHER, HARNESS CLIP SCREW
    SERIAL 03332138-03462607
    WASHER, HARNESS CLIP SCREW
    SERIAL 03332138-03462607
  • 40
    36405 OIL PUMP ASSEMBLY
    OIL PUMP ASSEMBLY
  • --
    27-34460 GASKET, OIL PUMP COVER
    GASKET, OIL PUMP COVER
  • 41
    10-8M0043993 SCREW, OIL PUMP TO CYLINDER BLOCK (3/4")
    SCREW, OIL PUMP TO CYLINDER BLOCK (3/4")
  • 42
    52146 SCREEN ASSEMBLY, OIL PUMP
    SCREEN ASSEMBLY, OIL PUMP
  • --
    10-8M0040582 SCREW, OIL PUMP SCREEN SUPPORT CLAMPING
    SCREW, OIL PUMP SCREEN SUPPORT CLAMPING
  • --
    60717 SUPPORT, OIL PUMP
    SUPPORT, OIL PUMP
  • 43
    22-805632 CONNECTOR, OIL FILTER TO CYLINDER BLOCK
    CONNECTOR, OIL FILTER TO CYLINDER BLOCK
  • 44
    35-866340Q03 OIL FILTER ASSEMBLY
    OIL FILTER ASSEMBLY
  • 45
    59341A1 COVER ASSEMBLY, CRANKCASE
    COVER ASSEMBLY, CRANKCASE
  • 46
    26-97335 OIL SEAL, CRANKCASE COVER
    OIL SEAL, CRANKCASE COVER
  • 47
    27-49953 GASKET, CRANKCASE COVER
    GASKET, CRANKCASE COVER
  • 48
    10-8M0040582 SCREW, COVER TO CYLINDER BLOCK (7/16")
    SERIAL 03332138-03462607
    SCREW, COVER TO CYLINDER BLOCK (7/16")
    SERIAL 03332138-03462607
  • 48
    10-8M0040582 SCREW, COVER TO CYLINDER BLOCK (7/16")
    SERIAL 03462608-03771645
    SCREW, COVER TO CYLINDER BLOCK (7/16")
    SERIAL 03462608-03771645
  • 48
    10-29179 SCREW, COVER TO CYLINDER BLOCK (1")
    SERIAL 03462608-03771644
    SCREW, COVER TO CYLINDER BLOCK (1")
    SERIAL 03462608-03771644
  • 49
    52583A1 OIL PAN ASSEMBLY
    OIL PAN ASSEMBLY
  • 50
    27-14901A1 GASKET SET, OIL PAN
    GASKET SET, OIL PAN
  • 51
    10-72607 SCREW, OIL PAN TO CYLINDER BLOCK (1/4")
    SCREW, OIL PAN TO CYLINDER BLOCK (1/4")
  • 52
    10-34500 SCREW, OIL PAN TO CYLINDER BLOCK (5/16")
    SCREW, OIL PAN TO CYLINDER BLOCK (5/16")
  • 53
    10-49956 SCREW, DRAIN - OIL PAN
    SCREW, DRAIN - OIL PAN
  • 54
    27-8M0077608 GASKET, OIL PAN DRAIN SCREW
    GASKET, OIL PAN DRAIN SCREW
