LIGHTING SYSTEM для Ktm 950 SMR AUS/UK - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    58614001100 HEAD LIGHT LEFT TR.
    HEAD LIGHT LEFT TR.
  • 6
    58614001050 RUBBER CAP FOR HEAD LIGHT
    RUBBER CAP FOR HEAD LIGHT
  • 7
    49011435100 BULB 12V 5W (W2,1X9,5D) PHIL.
    BULB 12V 5W (W2,1X9,5D) PHIL.
  • 8
    57111038000 BULB H4 12V 60/55W (P43T)
    BULB H4 12V 60/55W (P43T)
  • 12
    0016050121 SCREW FOR PLASTIC 50X12
    SCREW FOR PLASTIC 50X12
  • 20
    58414025100 FLASHER CPL.FRONT L/S REAR R/S
    FLASHER CPL.FRONT L/S REAR R/S
  • 21
    58414026100 FLASHER CPL.FRONT R/S REAR L/S
    FLASHER CPL.FRONT R/S REAR L/S
  • 22
    44111015100 BULB 12V 10W (BA15S)
    BULB 12V 10W (BA15S)
  • 23
    0125100003 WASHER DIN0125-A10,5
    WASHER DIN0125-A10,5
  • 24
    58414030000 HH COLLAR NUT M10X1,25 WS=13
    HH COLLAR NUT M10X1,25 WS=13
  • 25
    0797100003 LOCK WASHER DIN6797-J10,5 ZI
    LOCK WASHER DIN6797-J10,5 ZI
  • 26
    58414028100 FLASHER LENS L/S & R/S
    FLASHER LENS L/S & R/S
  • 30
    58614040044 REAR LIGHT CPL. RED
    REAR LIGHT CPL. RED
  • 31
    58614040050 METAMOLL FOR HEAD LIGHT
    METAMOLL FOR HEAD LIGHT
  • 32
    60014048000 BULB 12V 21W
    BULB 12V 21W
  • 33
    0985060003 SELF LOCK. NUT DIN0985-M 6
    SELF LOCK. NUT DIN0985-M 6
  • 34
    0021060003 WASHER DIN9021-A 6,4
    WASHER DIN9021-A 6,4
  • 35
    58214069051 RUBBER GROMMET 16X10,8X3
    RUBBER GROMMET 16X10,8X3
  • 39
    62511076000 WIRING HARNESS REAR
    WIRING HARNESS REAR
  • 40
    58414047000 LICENSE-PLATE ILLUMINATION
    LICENSE-PLATE ILLUMINATION
  • 41
    0021050003 WASHER DIN9021-A 5,3
    WASHER DIN9021-A 5,3
  • 42
    0985050003 SELF LOCKING NUT DIN0985-M 5
    SELF LOCKING NUT DIN0985-M 5
  • 43
    58614021100 ADJ. SCREW HEAD LIGHT
    ADJ. SCREW HEAD LIGHT
  • 44
    0770080020 O-RING 8X2 SILICONE
    O-RING 8X2 SILICONE
  • 45
    58614024000 CLAMPRING F. HEAD LIGHT ADJ.
    CLAMPRING F. HEAD LIGHT ADJ.
  • 46
    58614018000 ADJUSTINGNUT F. HEAD L. ADJ.
    ADJUSTINGNUT F. HEAD L. ADJ.
  • 48
    62514063050 TAB HEAD LIGHT ADJ.
    TAB HEAD LIGHT ADJ.
  • 76
    58611076100 CABLE HARNESS REAR PART
    CABLE HARNESS REAR PART
