EXHAUST SYSTEM для Ktm 950 SMR AUS/UK - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    62505007100 EXHAUST PIPE FRONT
    EXHAUST PIPE FRONT
  • 2
    62505008000 EXHAUST PIPE REAR
    EXHAUST PIPE REAR
  • 3
    60005005000 GASKET
    GASKET
  • 4
    61005009000 SPACER BUSH. 8,5X15X7,5
    SPACER BUSH. 8,5X15X7,5
  • 5
    51010086100 SELF LOCKING NUT M 8 CU
    SELF LOCKING NUT M 8 CU
  • 6
    0908100000 PLUG DIN0908-M10X1 A2
    PLUG DIN0908-M10X1 A2
  • 7
    0603100141 COPPER GASKET DIN7603-10X14X1
    COPPER GASKET DIN7603-10X14X1
  • 10
    61005007049 CLAMP EXHAUST PIPE
    CLAMP EXHAUST PIPE
  • 11*
    0025080406 HH COLLAR SCREW M8X40 TX40
    HH COLLAR SCREW M8X40 TX40
  • 12
    0125080003 WASHER DIN0125-A 8,4
    WASHER DIN0125-A 8,4
  • 13
    51005067000 INSOLATE WASHER 8,5X28X3
    INSOLATE WASHER 8,5X28X3
  • 14
    58405050065 COLLAR BUSH 8,5X12X23,5X10
    COLLAR BUSH 8,5X12X23,5X10
  • 15
    62505015150 EXHAUST PIPE BRACKET FRONT
    EXHAUST PIPE BRACKET FRONT
  • 16*
    0025080356 HH COLLAR SCREW M8X35 TX40
    HH COLLAR SCREW M8X35 TX40
  • 20
    61005051100 CLAMP CPL. D=53,2MM
    CLAMP CPL. D=53,2MM
  • 21
    58405005001 GRAPHITRING 45X50X25
    GRAPHITRING 45X50X25
  • 29
    0991080353 FLAT HEAD SCREW DIN7991-M 8X35
    FLAT HEAD SCREW DIN7991-M 8X35
  • 30
    61005052000 EXHAUST CLAMP CPL.
    EXHAUST CLAMP CPL.
  • 31
    62505048100 DISTRIBUTOR TUBE
    DISTRIBUTOR TUBE
  • 32*
    0025080306 HH COLLAR SCREW M8X30 TX40
    HH COLLAR SCREW M8X30 TX40
  • 33
    58303061100 SPECIAL WASHER ALU 8X24 MM ELO
    SPECIAL WASHER ALU 8X24 MM ELO
  • 34
    62505069000 SPACER BUSH. 8,5X12X18MM
    SPACER BUSH. 8,5X12X18MM
  • 35
    54305068100 DAMP. COMPONENT SILICONE GREY
    DAMP. COMPONENT SILICONE GREY
  • 36*
    0025080166 HH COLLAR SCREW M8X16 TX40
    HH COLLAR SCREW M8X16 TX40
  • 37
    62505047000 THERMAL SHIELD
    THERMAL SHIELD
  • 38
    58605083010 SCREW TORX M5X10
    SCREW TORX M5X10
  • 39
    60005005002 EXHAUST GASKET
    EXHAUST GASKET
  • 40*
    62605082000 SILENCER L/S
    SILENCER L/S
  • 41*
    62605083000 SILENCER R/S
    SILENCER R/S
  • 42
    54308042000 RUBBER BUFFER
    RUBBER BUFFER
  • 43
    60005095000 CLAMP FOR SILENCER CPL.
    CLAMP FOR SILENCER CPL.
  • 44
    6000508500001S SILENCER/HANDLE HOLDER L/S
    SILENCER/HANDLE HOLDER L/S
  • 45
    6000508600001S SILENCER/HANDLE HOLDER R/S
    SILENCER/HANDLE HOLDER R/S
  • 46*
    0025080256 HH COLLAR SCREW M8X25 TX40
    HH COLLAR SCREW M8X25 TX40
  • 47
    0021080003 WASHER DIN9021-A 8,4
    WASHER DIN9021-A 8,4
  • 48
    0797050000 TOOTH LOCK WASHER DIN6797-J
    TOOTH LOCK WASHER DIN6797-J
