EVAPORATIVE CANISTER для Ktm 950 Super Enduro - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    58715001000 EVAP.CANISTER FILTER TYPE AK47
    EVAP.CANISTER FILTER TYPE AK47
  • 2
    60015022000 T-CONNECTOR TS-6
    T-CONNECTOR TS-6
  • 3
    60015025000 Y-CONNECTING PIECE YS 6-8-6
    Y-CONNECTING PIECE YS 6-8-6
  • 8
    60015025100 Y-CONNECTING PIECE YS 6-6-6
    Y-CONNECTING PIECE YS 6-6-6
  • 10
    60015030000 VALVE MIKUNI CI-41-04
    VALVE MIKUNI CI-41-04
  • 11
    60015031000 VALVE MIKUNI CI-41-05
    VALVE MIKUNI CI-41-05
  • 13
    60031098001 HOSE 3,2X8,5 PER METER
    HOSE 3,2X8,5 PER METER
  • 14
    60007026001 HOSE NBR 5,4X9,4 PER METER
    HOSE NBR 5,4X9,4 PER METER
  • 15
    60007116001 HOSE 6X12 PER METER
    HOSE 6X12 PER METER
  • 16
    60015019001 HOSE NBR 7X11 PER METER
    HOSE NBR 7X11 PER METER
  • 19
    58007017000 YDNAC CLAMP 10101 (9MM)
    YDNAC CLAMP 10101 (9MM)
  • 22
    58031005000 CLAMP YDNAC 10128 12MM
    CLAMP YDNAC 10128 12MM
  • 28
    50303018000 RUBBER L=145MM
    RUBBER L=145MM
  • 31
    60015011000 BRACKET FOR EVAP-VALVE
    BRACKET FOR EVAP-VALVE
  • 33
    60015013000 BUSHING EVAP-VALVE
    BUSHING EVAP-VALVE
  • 34
    36003014000 LOCK WASHER 8MM
    LOCK WASHER 8MM
  • 35
    0125080003 WASHER DIN0125-A 8,4
    WASHER DIN0125-A 8,4
  • 36
    0015060123 HH COLLAR SCREW M 6X12 WS=8
    HH COLLAR SCREW M 6X12 WS=8
  • 37
    0015080103 HH COLLAR SCREW M 8X10 WS=10
    HH COLLAR SCREW M 8X10 WS=10
  • 38
    0015080163 HH COLLAR SCREW M 8X16 WS=10
    HH COLLAR SCREW M 8X16 WS=10
  • 43
    60015033000 COVER CAP EVAP.CANIST.VALVE
    COVER CAP EVAP.CANIST.VALVE
  • 44
    60015034000 PLUG FOR EVAP.CANISTER SYST.
    PLUG FOR EVAP.CANISTER SYST.
  • 45
    60036023000 VACUUM CONECT. M6/1MM M-GROOVE
    VACUUM CONECT. M6/1MM M-GROOVE
  • 46
    58336020190 VACUUM CONECTION M6/3MM
    VACUUM CONECTION M6/3MM
