BRAKE CALIPER FRONT для Ktm 950 Super Enduro - 2007 года выпуска

  • №
    Артикул
    Название
  • 2
    60113015000 BRAKE CALIPER FRONT L/S
    BRAKE CALIPER FRONT L/S
  • 3
    60013018000 RETAINING PLATE SET FRONT
    RETAINING PLATE SET FRONT
  • 4
    54613218000 CUP SET SHORT
    CUP SET SHORT
  • 6
    60013020000 BLEEDER SCREW WITH CAP
    BLEEDER SCREW WITH CAP
  • 7
    60013030000 BRAKE PAD SET FR.TT2172HHA
    BRAKE PAD SET FR.TT2172HHA
  • 9
    60013017000 BOLT SET L/S
    BOLT SET L/S
  • 12
    63013012000 BRAKE HOSE FRONT
    BRAKE HOSE FRONT
  • 14
    50213025000 HOLLOW SCREW M10X1X19
    HOLLOW SCREW M10X1X19
  • 15
    42013226000 CU-SEAL RING DIN7603-10X16X1
    CU-SEAL RING DIN7603-10X16X1
  • 16
    60013083000 BRAKE PISTONS
    BRAKE PISTONS
  • 17
    60013019000 REP.KIT SEALING RINGS 30/32MM
    REP.KIT SEALING RINGS 30/32MM
  • 19
    60113049100 BRAKE CALIPER SUPPORT FR. L/S
    BRAKE CALIPER SUPPORT FR. L/S
  • 21
    0015080353 HH COLLAR SCREW M 8X35 WS=10
    HH COLLAR SCREW M 8X35 WS=10
