FRAME W/ SUB-FRAME для Ktm 950 ADVENTURE - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    6000300100030 FRAME LC8 ADVENTURE
    FRAME LC8 ADVENTURE
  • 2
    54603048000 RANGE CHANGE METAL NUT M8
    RANGE CHANGE METAL NUT M8
  • 3
    54603048100 RANGE CHANGE METAL NUT M6
    RANGE CHANGE METAL NUT M6
  • 4
    0015080403 HH COLLAR SCREW M8X40 WS=10
    HH COLLAR SCREW M8X40 WS=10
  • 5
    58403060000 CHAIN ROLL 12X29X22.5
    CHAIN ROLL 12X29X22.5
  • 6
    58403060065 BUSH CHAIN ROLL 8X12X23
    BUSH CHAIN ROLL 8X12X23
  • 7
    36003014000 LOCK WASHER 8MM
    LOCK WASHER 8MM
  • 8
    60004076000 CHAIN SLIDING BLOCK
    CHAIN SLIDING BLOCK
  • 9
    0015060163 HH COLLAR SCREW 16X16 WS=8
    HH COLLAR SCREW 16X16 WS=8
  • 10
    58303070000 STOP RUBBER MB
    STOP RUBBER MB
  • 11
    0934080003 HEXAGON NUT DIN0934-M8
    HEXAGON NUT DIN0934-M8
  • 12
    60003088000 PLASTIC CAP FOR MS
    PLASTIC CAP FOR MS
  • 13
    54630044000 COLLAR NUT M10 WS=13
    COLLAR NUT M10 WS=13
  • 14
    60003013000 ENGINE BRAC. SCREW M10X172
    ENGINE BRAC. SCREW M10X172
  • 15
    60003014000 ENGINE BRAG. SCREW M10X206
    ENGINE BRAG. SCREW M10X206
  • 16
    60003005000 ENGINE SUPPORT LEFT
    ENGINE SUPPORT LEFT
  • 17
    60003006000 ENGINE SUPPORT RIGHT
    ENGINE SUPPORT RIGHT
  • 18
    60003098000 RUBBER SLEEVE
    RUBBER SLEEVE
  • 19
    0015100243 HH COLLAR SCREW M10X24 WS=13
    HH COLLAR SCREW M10X24 WS=13
  • 20
    54310086100 SELF LOCKING NUT M10 CU WS=14
    SELF LOCKING NUT M10 CU WS=14
  • 21
    60003002000 SUB FRAME ALUMINIUM LC8
    SUB FRAME ALUMINIUM LC8
  • 22
    60003004027 FL.HEAD SCREW M10X1,25 L-27
    FL.HEAD SCREW M10X1,25 L-27
  • 23
    60003001051 COLLAR BUSHING 10X15X25X4
    COLLAR BUSHING 10X15X25X4
  • 27
    60003087000 SPLASH PROTECTOR FRAME
    SPLASH PROTECTOR FRAME
  • 30
    60003091000 UNDERRIDE PROTECTION
    UNDERRIDE PROTECTION
  • 31
    60003092000 UNDERRIDE PROTECTION LEFT
    UNDERRIDE PROTECTION LEFT
  • 32
    60003093000 UNDERRIDE PROTECTION RIGHT
    UNDERRIDE PROTECTION RIGHT
  • 33
    60003094000 LOWER TANK HOLDER FRONT
    LOWER TANK HOLDER FRONT
  • 34
    60003097000 COLLAR SCREW
    COLLAR SCREW
  • 35
    60003095000 CAGE NUT M6 SL 4
    CAGE NUT M6 SL 4
  • 36
    0014060153 HH C0LLAR SCREW M6X15 W 8
    HH C0LLAR SCREW M6X15 W 8
  • 37
    60003096000 VIBRATION DAMPER
    VIBRATION DAMPER
  • 38
    0015080163 HH COLLAR SCREW M 8X16 WS=10
    HH COLLAR SCREW M 8X16 WS=10
  • 40
    59003040250 FOOT PED L/S SILVER
    FOOT PED L/S SILVER
  • 41
    59003041250 FOOTPED R/S SILVER
    FOOTPED R/S SILVER
  • 42
    54803044000 BOLT FOR FOOT PED
    BOLT FOR FOOT PED
  • 43
    54603041000 FOOTREST SPRING US & R/S
    FOOTREST SPRING US & R/S
  • 44
    0125100003 WASHER DIN0125-A10.5
    WASHER DIN0125-A10.5
  • 45
    0094032253 PIN DIN0094-3,2X25 STEEL
    PIN DIN0094-3,2X25 STEEL
  • 46
    60003040010 FOOTREST RUBBER FRONT US
    FOOTREST RUBBER FRONT US
  • 47
    60003041010 FOOTREST RUBBER FRONT R/S
    FOOTREST RUBBER FRONT R/S
  • 48
    60003044010 CLOSING PANEL FRONT US R/S
    CLOSING PANEL FRONT US R/S
  • 49
    0985050003 SELF LOCKING NUT DIN0985-M5
    SELF LOCKING NUT DIN0985-M5
  • 50
    60003048000 FOOTREST BRACKET REAR US
    FOOTREST BRACKET REAR US
  • 51
    60003049000 FOOTREST BRACKET REAR R/S
    FOOTREST BRACKET REAR R/S
  • 52
    54510052100 SPROCKET-SCREW-AN M6X26 WS=6
    SPROCKET-SCREW-AN M6X26 WS=6
  • 53
    54403135000 PLASTIC CAP SFL10
    PLASTIC CAP SFL10
  • 54
    60003050000 FOOTREST CPL. L/S REAR
    FOOTREST CPL. L/S REAR
  • 55
    60003051000 FOOTREST CPL. R/S REAR
    FOOTREST CPL. R/S REAR
  • 56
    60003044000 BOLT FOR FOOTREST REAR
    BOLT FOR FOOTREST REAR
  • 57
    60003152000 ENGAGE PANEL FOOTREST L/S
    ENGAGE PANEL FOOTREST L/S
  • 58
    60003052000 ENGAGE PANEL FOOTREST R/S
    ENGAGE PANEL FOOTREST R/S
  • 59
    0799060003 TAB WASHER DIN6799-RS 6,0
    TAB WASHER DIN6799-RS 6,0
