LIGHT SYSTEM для Ktm 660 SMC - 2005 года выпуска

  • №
    Артикул
    Название
  • 6
    50211537000 RUBBER CAP
    RUBBER CAP
  • 7
    49011435000 BULB 12V 5W (W2,1X9,5D)
    BULB 12V 5W (W2,1X9,5D)
  • 8
    57111038000 BULB H4 12V 60/55W (P43T)
    BULB H4 12V 60/55W (P43T)
  • 9
    58414010100 HEAD LIGHT SUPPORT
    HEAD LIGHT SUPPORT
  • 10
    59014002000 HEAD LIGHT 186(RI)"1003202 R"
    HEAD LIGHT 186(RI)"1003202 R"
  • 10
    59014002100 HEAD LIGHT 186(LE)"1003203 L"
    HEAD LIGHT 186(LE)"1003203 L"
  • 13
    0016040183 SCREW
    SCREW
  • 15
    49011436100 BULB HOLDER
    BULB HOLDER
  • 18
    0125060003 WASHER DIN0125-A 6,4
    WASHER DIN0125-A 6,4
  • 19
    0933060203 HH SCREW DIN0933-M 6X20
    HH SCREW DIN0933-M 6X20
  • 20
    5841402500030 FLASHER CPL.FRONT L/S REAR R/S
    FLASHER CPL.FRONT L/S REAR R/S
  • 21
    5841402600030 FLASHER CPL.FRONT R/S REAR L/S
    FLASHER CPL.FRONT R/S REAR L/S
  • 22
    58414028000 FLASHER LENS L/S & R/S
    FLASHER LENS L/S & R/S
  • 23
    44111015100 BULB 12V 10W (BA15S)
    BULB 12V 10W (BA15S)
  • 25
    0797100003 LOCK WASHER DIN6797-J10,5 ZI
    LOCK WASHER DIN6797-J10,5 ZI
  • 26
    58414030000 HH COLLAR NUT M10X1,25 WS=13
    HH COLLAR NUT M10X1,25 WS=13
  • 30
    58614040044 REAR LIGHT CPL.
    REAR LIGHT CPL.
  • 31
    58614040050 METAMOLL
    METAMOLL
  • 32
    60014048000 BULB 12V 21W
    BULB 12V 21W
  • 33
    0985060003 SELF LOCK. NUT DIN0985-M 6
    SELF LOCK. NUT DIN0985-M 6
  • 34
    0021060003 WASHER DIN9021-A 6,4
    WASHER DIN9021-A 6,4
  • 35
    58214069051 RUBBER GROMMET 16X10,8X3 02
    RUBBER GROMMET 16X10,8X3 02
  • 40
    58414047000 LICENSE-PLATE ILLUMINATION
    LICENSE-PLATE ILLUMINATION
  • 41
    0021050003 WASHER DIN9021-A 5,3
    WASHER DIN9021-A 5,3
  • 42
    0985050003 SELF LOCKING NUT DIN0985-M 5
    SELF LOCKING NUT DIN0985-M 5
  • 76
    58611076100 CABLE HARNESS REAR PART
    CABLE HARNESS REAR PART
