ENGINE CASE для Ktm 660 SMC - 2005 года выпуска`
-
№АртикулНазвание
-
15733000004423 ENGINE CASE CPL.W.TRAN.BEAR.ENGINE CASE CPL.W.TRAN.BEAR.
-
550130027000 DOWEL 19 X15,1X12DOWEL 19 X15,1X12
-
651030026100 DOWEL 17 X 14 X 12DOWEL 17 X 14 X 12
-
750130010000 CRANK CASE BUSHCRANK CASE BUSH
-
958033097000 NEEDLE BEARING HK 2216NEEDLE BEARING HK 2216
-
1058330011000 SHIFT MECHANISM SUPPORTSHIFT MECHANISM SUPPORT
-
1149030090000 DOWEL 9,8 X 7 X 10DOWEL 9,8 X 7 X 10
-
1556530017000 RETAINING PLATERETAINING PLATE
-
160991060166 FL.HEAD SCR.DIN7991-M6X16 10.9FL.HEAD SCR.DIN7991-M6X16 10.9
-
180015080163 HH COLLAR SCREW M 8X16 WS=10HH COLLAR SCREW M 8X16 WS=10
-
190603082121 SEAL RING CU DIN7603- 8X12X1SEAL RING CU DIN7603- 8X12X1
-
2058530039300 ENGI.CASE GASKET POLY. 0,43ENGI.CASE GASKET POLY. 0,43
-
210985050103 OVAL HEAD SCR. DIN7985-M 5X10OVAL HEAD SCR. DIN7985-M 5X10
-
230412174012 CYLIND.ROLL.NJ 203 ECP/C3 2001CYLIND.ROLL.NJ 203 ECP/C3 2001
-
240625618050 BALL BEARING 61805 C3BALL BEARING 61805 C3
-
2660030064070 OIL JET 70 M6X0,75 WS8OIL JET 70 M6X0,75 WS8
-
2749030029000 OIL DRAIN PLUG M10X1,5 AH-WS=6OIL DRAIN PLUG M10X1,5 AH-WS=6
-
2849130450050 TUBE LW 3TUBE LW 3
-
290603100141 COPPER GASKET DIN7603-10X14X1COPPER GASKET DIN7603-10X14X1
-
305833010124423 CLUTCH COVER CPL. GREYCLUTCH COVER CPL. GREY
-
3158530025000 CLUTCH COVER GASKETCLUTCH COVER GASKET
-
3358030020100 PLUG CPL. M24X3PLUG CPL. M24X3
-
340770191015 O-RING 19,00X3,00 NBRO-RING 19,00X3,00 NBR
-
3561030019050 CIRCLIP OIL LEVEL GLASSCIRCLIP OIL LEVEL GLASS
-
3659030019000 OIL LEVEL GLASS G 1777 YOIL LEVEL GLASS G 1777 Y
-
3858333041000 BUMP RUBBERBUMP RUBBER
-
3958630047100 CHAIN DAMPER SHEET 17TCHAIN DAMPER SHEET 17T
-
4258030050700 CHAIN COVER BLACKCHAIN COVER BLACK
-
430912060303 AH SCREW DIN0912-M 6X30AH SCREW DIN0912-M 6X30
-
4458030021000 OILDRAIN PLUG W.MAG. M 12X1,5OILDRAIN PLUG W.MAG. M 12X1,5
-
4558038017100 CU-SEAL RING DIN7603-22X27X2CU-SEAL RING DIN7603-22X27X2
-
4658038019100 OIL DRAIN PLUG M22X1,5OIL DRAIN PLUG M22X1,5
-
4758038022000 CU-SEAL RING DIN7603-12X18X1,5CU-SEAL RING DIN7603-12X18X1,5
-
480908120153 PLUG DIN0908-M12X1,5PLUG DIN0908-M12X1,5
-
5058538023000 OIL PRES.SPRING 5 BAR REDOIL PRES.SPRING 5 BAR RED
-
5158038028000 VALVE PISTON D=10MMVALVE PISTON D=10MM
-
5558430099200 GASKET SETGASKET SET
-
600015060253 HH COLLAR SCREW M 6X25 WS=8HH COLLAR SCREW M 6X25 WS=8
-
610015060303 HH COLLAR SCREW M 6X30 WS=8HH COLLAR SCREW M 6X30 WS=8
-
620015060353 HH COLLAR SCREW M 6X35 WS=8HH COLLAR SCREW M 6X35 WS=8
-
630015060403 HH COLLAR SCREW M 6X40 WS=8HH COLLAR SCREW M 6X40 WS=8
-
660015060553 HH COLLAR SCREW M 6X55 WS=8HH COLLAR SCREW M 6X55 WS=8
-
680015060653 HH COLLAR SCREW M 6X65 WS=8HH COLLAR SCREW M 6X65 WS=8
