ENGINE CASE для Ktm LC4 640 Duke - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    5843000014430 ENGINE CASE CPL.W.TR.BEAR (BLACK)
    ENGINE CASE CPL.W.TR.BEAR (BLACK)
  • 5
    50130027000 DOWEL 19 X15,1X12
    DOWEL 19 X15,1X12
  • 6
    51030026100 DOWEL 17 X14 X12
    DOWEL 17 X14 X12
  • 7
    50130010000 CRANK CASE BUSH
    CRANK CASE BUSH
  • 9
    58033097000 NEEDLE BEARING HK 2216 KSE
    NEEDLE BEARING HK 2216 KSE
  • 10
    58330011000 SHIFT MECHANISM SUPPORT
    SHIFT MECHANISM SUPPORT
  • 11
    49030090000 DOWEL 9,8 X 7 X 10
    DOWEL 9,8 X 7 X 10
  • 15
    56530017000 RETAINING BRACKET
    RETAINING BRACKET
  • 16
    0991060163 FLAT HEAD SCR. DIN7991-M 6X16
    FLAT HEAD SCR. DIN7991-M 6X16
  • 17
    50332095000 NEEDLE BEARING HK 1212
    NEEDLE BEARING HK 1212
  • 18
    0015080163 HH COLLAR SCREW M 8X16 WS=10
    HH COLLAR SCREW M 8X16 WS=10
  • 19
    0603082121 SEAL RING CU DIN7603- 8X12X1
    SEAL RING CU DIN7603- 8X12X1
  • 20
    58430039100 ENGINE CASE GASKET LC4 02
    ENGINE CASE GASKET LC4 02
  • 21
    0985050103 OVAL HEAD SCR. DIN7985-M 5X10
    OVAL HEAD SCR. DIN7985-M 5X10
  • 23
    0625160030 GROOVED BALL BEARING 16003 C3
    GROOVED BALL BEARING 16003 C3
  • 24
    0625618050 BALL BEARING 61805 C3
    BALL BEARING 61805 C3
  • 28
    58440091000 STOP DISK 33 X 58 X 1,5
    STOP DISK 33 X 58 X 1,5
  • 30
    58330101100 CLUTCH COVER CPL.BLA.
    CLUTCH COVER CPL.BLA.
  • 31
    58330025000 CLUTCH COVER GASKET
    CLUTCH COVER GASKET
  • 33
    58330020144 OIL DIPSTICK CPL. L=93MM
    OIL DIPSTICK CPL. L=93MM
  • 34
    0770160030 O-RING 16,00X3,00 NBR 70
    O-RING 16,00X3,00 NBR 70
  • 38
    58333041000 BUMP RUBBER
    BUMP RUBBER
  • 39
    58730047000 CHAIN DAMPER SHEET 17Z
    CHAIN DAMPER SHEET 17Z
  • 40
    58430060000 SPROCKET COVER BLACK
    SPROCKET COVER BLACK
  • 41
    54613038150 BUSHING 6,5X8X11
    BUSHING 6,5X8X11
  • 42
    58430047000 CHAIN DAMPERSHEET 17T
    CHAIN DAMPERSHEET 17T
  • 42
    58430047100 CHAIN DAMPERSHEET 15/16T
    CHAIN DAMPERSHEET 15/16T
  • 44
    58030021000 OILDRAIN PLUG W.MAG. M 12X1,5
    OILDRAIN PLUG W.MAG. M 12X1,5
  • 45
    58038017100 CU-SEAL RING DIN7603-22X27X2
    CU-SEAL RING DIN7603-22X27X2
  • 46
    58038019100 OIL DRAIN PLUG M22X1,5
    OIL DRAIN PLUG M22X1,5
  • 47
    58038022000 CU-SEAL RING DIN7603-12X18X1,5
    CU-SEAL RING DIN7603-12X18X1,5
  • 48
    0908120153 PLUG DIN0908-M12X1,5
    PLUG DIN0908-M12X1,5
  • 50
    58038023300 PRESSURE SPRING L=25MM D=1MM
    PRESSURE SPRING L=25MM D=1MM
  • 51
    58038028000 VALVE PISTON D=10MM
    VALVE PISTON D=10MM
  • 55
    58430099100 GASKET SET LC4 2002
    GASKET SET LC4 2002
  • 60
    0015060253 HH COLLAR SCREW M 6X25 WS=8
    HH COLLAR SCREW M 6X25 WS=8
  • 61
    0015060303 HH COLLAR SCREW M 6X30 WS=8
    HH COLLAR SCREW M 6X30 WS=8
  • 62
    0015060353 HH COLLAR SCREW M 6X35 WS=8
    HH COLLAR SCREW M 6X35 WS=8
  • 63
    0015060403 HH COLLAR SCREW M 6X40 SW=8
    HH COLLAR SCREW M 6X40 SW=8
  • 66
    0015060553 HH COLLAR SCREW M 6X55 WS=8
    HH COLLAR SCREW M 6X55 WS=8
  • 68
    0015060653 HH COLLAR SCREW M 6X65 WS=8
    HH COLLAR SCREW M 6X65 WS=8
  • 75
    0015060953 HH COLLAR SCREW M 6X95 WS=8
    HH COLLAR SCREW M 6X95 WS=8
  • 77
    0015060303 HH COLLAR SCREW M 6X30 WS=8
    HH COLLAR SCREW M 6X30 WS=8
