LUBRICATIN SYSTEM для Ktm 525 XC - 2009 года выпуска
-
№АртикулНазвание
-
183038002000 OIL PUMP SHAFTOIL PUMP SHAFT
-
259038011010 OILPUMP ROTOR CPL. 10MM G-73ROILPUMP ROTOR CPL. 10MM G-73R
-
377038011000 OILPUMP ROTOR 15MM G-164OILPUMP ROTOR 15MM G-164
-
458438001000 OIL PUMP GEAR 26-TOIL PUMP GEAR 26-T
-
559038004000 OIL PUMP COVER L/SOIL PUMP COVER L/S
-
659038003000 OIL PUMP COVER R/S 8MMOIL PUMP COVER R/S 8MM
-
70025050166 HH COLLAR SCREW M5X16HH COLLAR SCREW M5X16
-
80984050122 AH SCREW DIN6912-M 5X12AH SCREW DIN6912-M 5X12
-
1159038041000 OIL FILTER COVER RACINGOIL FILTER COVER RACING
-
1258038005100 OIL FILTER LONGOIL FILTER LONG
-
1359038046100 OIL FILTER SHORTOIL FILTER SHORT
-
140402251980 NEEDLEROL.DIN5402 NRA 2,5X19,8NEEDLEROL.DIN5402 NRA 2,5X19,8
-
150402251180 NEEDLE ROLLER DIN5402 2,5X11,8NEEDLE ROLLER DIN5402 2,5X11,8
-
1658038029000 BANJO BOLT M8X1BANJO BOLT M8X1
-
1759038029000 JET SCREW ''100'' M8X1 WS=12JET SCREW ''100'' M8X1 WS=12
-
180603082121 SEAL RING CU DIN7603- 8X12X1SEAL RING CU DIN7603- 8X12X1
-
1959038035000 OIL LINE STEEL CASE-CYL.HEADOIL LINE STEEL CASE-CYL.HEAD
-
200770400025 O-RING 40,00X2,50 NBR 70O-RING 40,00X2,50 NBR 70
-
2177038017000 SCREW PLUGSCREW PLUG
-
2259038016000 OIL SCREEN 15X83MMOIL SCREEN 15X83MM
-
230770125015 O-RING 12,5X1,5 NBRO-RING 12,5X1,5 NBR
-
240770020170 O-RING 17,17X1,78 GLOO-RING 17,17X1,78 GLO
-
2558038007755 STOP DISK 8,1 X 15 X 0,5STOP DISK 8,1 X 15 X 0,5
-
260799060000 TAB WASHER DIN6799-RS 6,0TAB WASHER DIN6799-RS 6,0
-
2758405098000 RUBBERBUFFER 8X17X10 SILENCRUBBERBUFFER 8X17X10 SILENC
