COWLING для Kawasaki Voyager XII - 2001 года выпуска

  • №
    Артикул
    Название
  • 11012
    11012-1550 CAP
    CAP
  • 13227
    13227-1012 HOUSING, SHUTTER
    HOUSING, SHUTTER
  • 14024
    14024-1186 COVER, METER
    COVER, METER
  • 14024A
    14024-1192 COVER, LOUVER, UPPER (LEFT)
    COVER, LOUVER, UPPER (LEFT)
  • 14024B
    14024-1193 COVER, LOUVER, UPPER (RIGHT)
    COVER, LOUVER, UPPER (RIGHT)
  • 14024C
    14024-1194 COVER, LOUVER, LOWER (LEFT)
    COVER, LOUVER, LOWER (LEFT)
  • 14024D
    14024-1195 COVER, LOUVER, LOWER (RIGHT)
    COVER, LOUVER, LOWER (RIGHT)
  • 14024E
    14024-1280 COVER, WINDSHIELD
    COVER, WINDSHIELD
  • 14073
    14073-1245 DUCT, COWLING, UPPER (LEFT)
    DUCT, COWLING, UPPER (LEFT)
  • 14073A
    14073-1246 DUCT, COWLING, UPPER (RIGHT)
    DUCT, COWLING, UPPER (RIGHT)
  • 14073B
    14073-1247 DUCT, COWLING, LOWER (LEFT)
    DUCT, COWLING, LOWER (LEFT)
  • 14073C
    14073-1248 DUCT, COWLING, LOWER (RIGHT)
    DUCT, COWLING, LOWER (RIGHT)
  • 35019
    35019-1201-2T FLAP, UPPER (LEFT) (L.V.RED)
    FLAP, UPPER (LEFT) (L.V.RED)
  • 35019B
    35019-1202-2T FLAP, UPPER (RIGHT) (L.V.RED)
    FLAP, UPPER (RIGHT) (L.V.RED)
  • 35019D
    35019-1203-2T FLAP, LOWER (LEFT) (L.V.RED)
    FLAP, LOWER (LEFT) (L.V.RED)
  • 35019F
    35019-1204-2T FLAP, LOWER (RIGHT) (L.V.RED)
    FLAP, LOWER (RIGHT) (L.V.RED)
  • 39031
    39031-1058 CAP, END, TRIM
    CAP, END, TRIM
  • 39137
    39137-1057 STAY, COMP, COWLING
    STAY, COMP, COWLING
  • 39145
    39145-1072 TRIM, SEAL, WINDSHIELD COVER
    TRIM, SEAL, WINDSHIELD COVER
  • 39145A
    39145-1081 TRIM, SEAL, METER COVER
    TRIM, SEAL, METER COVER
  • 39145B
    39145-1082 TRIM, SEAL, METER COVER
    TRIM, SEAL, METER COVER
  • 39154
    39154-1144 WINDSHIELD
    WINDSHIELD
  • 42024
    42024-1002 SHUTTER, LOUVER
    SHUTTER, LOUVER
  • 53044
    53044-1150 TRIM, COWLING SIDE, UPPER
    TRIM, COWLING SIDE, UPPER
  • 53044A
    53044-1151 TRIM, COWLING SIDE, LOWER
    TRIM, COWLING SIDE, LOWER
  • 53044B
    53044-1181 TRIM, WINDSHIELD (LEFT)
    TRIM, WINDSHIELD (LEFT)
  • 53044C
    53044-1182 TRIM, WINDSHIELD (RIGHT)
    TRIM, WINDSHIELD (RIGHT)
  • 55022
    55022-1054-2T COVER, HEAD LAMP (L.V.RED)
    COVER, HEAD LAMP (L.V.RED)
  • 130
    130D0812 BOLT, FLANGED
    BOLT, FLANGED
  • 130A
    130D0835 BOLT, FLANGED, 8X35
    BOLT, FLANGED, 8X35
  • 130B
    130D0850 BOLT, FLANGED, 8X50
    BOLT, FLANGED, 8X50
  • 220
    220B0510 SCREW, PAN, CROS
    SCREW, PAN, CROS
  • 223
    223C0616 SCREW, PAN, WS, CROS
    SCREW, PAN, WS, CROS
  • 223A
    223C0625 SCREW, PAN, WS, CROS, 6X25
    SCREW, PAN, WS, CROS, 6X25
  • 224
    224C0510 SCREW, PAN, WP, CROS
    SCREW, PAN, WP, CROS
  • 235
    235B0408 SCREW, PAN, WP, CROS
    SCREW, PAN, WP, CROS
  • 55050D
    55050-5408-RI COWLING, UPPER (LEFT) (RED/BEIGE)/BLACK
    COWLING, UPPER (LEFT) (RED/BEIGE)/BLACK
  • 55050E
    55050-5409-RI COWLING, UPPER (RIGHT) (RED/BEIGE)/BLACK
    COWLING, UPPER (RIGHT) (RED/BEIGE)/BLACK
  • 92002
    92002-1830 BOLT, 6X25
    BOLT, 6X25
  • 92009
    92009-1181 SCREW, 6X18 (BLACK)
    SCREW, 6X18 (BLACK)
  • 92009A
    92009-1427 SCREW, 5X14
    SCREW, 5X14
  • 92015
    92015-1343 NUT, 5MM, COWLING
    NUT, 5MM, COWLING
  • 92015A
    92015-1710 NUT, 5MM
    NUT, 5MM
  • 92022
    92022-1516 WASHER, 3.3X8X0.5
    WASHER, 3.3X8X0.5
  • 92022A
    92022-1653 WASHER, 5.3X10X0.8
    WASHER, 5.3X10X0.8
  • 92022B
    92022-1808 WASHER, 6.5MM
    WASHER, 6.5MM
  • 92027
    92027-194 COLLAR, L=11.1
    COLLAR, L=11.1
  • 92037
    92037-1943 CLAMP, FLAP
    CLAMP, FLAP
  • 92039
    92039-1041 RIVET
    RIVET
  • 92071
    92071-1042 GROMMET, AIR FILTER
    GROMMET, AIR FILTER
  • 92075
    92075-1629 DAMPER
    DAMPER
  • 92075A
    92075-1883 DAMPER
    DAMPER
  • 92143
    92143-1025 COLLAR, L=6.5
    COLLAR, L=6.5
