RADIATOR для Kawasaki KX 450F - 2006 года выпуска

  • №
    Артикул
    Название
  • 132
    132L0625 BOLT, FLANGED, SMALL, 6X25
    BOLT, FLANGED, SMALL, 6X25
  • 14037
    14037-0036-RZ SCREEN (LEFT) (WHITE)
    SCREEN (LEFT) (WHITE)
  • 14037A
    14037-0037-RZ SCREEN (RIGHT) (WHITE)
    SCREEN (RIGHT) (WHITE)
  • 39061
    39061-0052 RADIATOR, ASSY. (LEFT)
    RADIATOR, ASSY. (LEFT)
  • 39061A
    39061-0053 RADIATOR, ASSY. (RIGHT)
    RADIATOR, ASSY. (RIGHT)
  • 49085
    49085-1078 CAP, ASSY., PRESSURE
    CAP, ASSY., PRESSURE
  • 92075
    92075-209 DAMPER
    DAMPER
  • 92152
    92152-0379 COLLAR, L=12.6, T=1.6
    COLLAR, L=12.6, T=1.6
  • 92153
    92153-0503 BOLT, 6X12
    BOLT, 6X12
  • 92192
    92192-0167 TUBE, 6X9X640
    TUBE, 6X9X640
  • 92200
    92200-0271 WASHER, 6.5X22X2.3
    WASHER, 6.5X22X2.3
