HANDLEBAR для Kawasaki KLR650 - 2006 года выпуска

  • №
    Артикул
    Название
  • 120
    120S0830 BOLT-SOCKET,8X30
    BOLT-SOCKET,8X30
  • 130
    130J0612 BOLT-FLANGED,6X12
    BOLT-FLANGED,6X12
  • 214
    214C0518 SCREW-PAN+-,5X18
    SCREW-PAN+-,5X18
  • 220
    220F0514 SCREW-PAN-CROSS,5X14
    SCREW-PAN-CROSS,5X14
  • 220A
    220F0620 SCREW-PAN-CROSS,6X20
    SCREW-PAN-CROSS,6X20
  • 11036
    11036-1297 BRACKET-A, LEVER HOLDER
    BRACKET-A, LEVER HOLDER
  • 13070
    13070-1131 GUIDE,THROTTLE PEACE
    GUIDE,THROTTLE PEACE
  • 13091
    13091-1255 HOLDER,ENGINE STOP SWITCH
    HOLDER,ENGINE STOP SWITCH
  • 14044
    14044-1062 HOLDER-CABLE,CLUTCH
    HOLDER-CABLE,CLUTCH
  • 27045
    27045-1071 SWITCH-ASSY,ENGINE STOP
    SWITCH-ASSY,ENGINE STOP
  • 32099
    32099-1072 CASE,THROTTLE,UPP
    CASE,THROTTLE,UPP
  • 32099A
    32099-1073 CASE,THROTTLE,LWR
    CASE,THROTTLE,LWR
  • 46003
    46003-1153 HANDLE
    HANDLE
  • 46012
    46012-1102 HOLDER-HANDLE,UPP
    HOLDER-HANDLE,UPP
  • 46019
    46019-1054 GRIP-ASSY,THROTTLE
    GRIP-ASSY,THROTTLE
  • 46055
    46055-009 SCREW,CABLE ADJUST,8MM
    SCREW,CABLE ADJUST,8MM
  • 46056
    46056-006 NUT,CABLE ADJUST
    NUT,CABLE ADJUST
  • 46075
    46075-1051 GRIP, LEFT HAND
    GRIP, LEFT HAND
  • 46076
    46076-1142 LEVER-ASSY-GRIP,CLUTCH
    LEVER-ASSY-GRIP,CLUTCH
  • 46091
    46091-1791 HOUSING-ASSY-CONTROL, LEFT HAND
    HOUSING-ASSY-CONTROL, LEFT HAND
  • 46092
    46092-1111 LEVER-GRIP,CLUTCH
    LEVER-GRIP,CLUTCH
  • 46092A
    46092-1123 LEVER-GRIP,CHOKE
    LEVER-GRIP,CHOKE
  • 56001
    56001-1204 MIREAROR-ASSY
    MIREAROR-ASSY
  • 59101
    59101-1106 REEL,THROTTLE
    REEL,THROTTLE
  • 59441
    59441-1073-260 COVER-HANDLE, LEFT HAND,A.RED (FOR 260)
    COVER-HANDLE, LEFT HAND,A.RED (FOR 260)
  • 59441A
    59441-1073-290 COVER-HANDLE, LEFT HAND,L.GREEN (FOR 777)
    COVER-HANDLE, LEFT HAND,L.GREEN (FOR 777)
  • 59441C
    59441-1074-260 COVER-HANDLE, RIGHT HAND,A.RED (FOR 260)
    COVER-HANDLE, RIGHT HAND,A.RED (FOR 260)
  • 59441D
    59441-1074-290 COVER-HANDLE, RIGHT HAND,L.GREEN (FOR 777)
    COVER-HANDLE, RIGHT HAND,L.GREEN (FOR 777)
  • 92002
    92002-1880 BOLT, LEVER SET
    BOLT, LEVER SET
  • 92015
    92015-1603 NUT,LOCK,FLANGED,6MM
    NUT,LOCK,FLANGED,6MM
  • 92022
    92022-1474 WASHER,ENGINE STOP SWITCH
    WASHER,ENGINE STOP SWITCH
  • 92022A
    92022-1896 WASHER
    WASHER
  • 92066
    92066-1216 PLUG
    PLUG
  • 92210
    92210-0006 NUT,LOCK,6MM
    NUT,LOCK,6MM
