SHOCK ABSORBER AND SWAY BAR ASSEMBLY для Arctic Cat CROSSFIRE 600 - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    2703-487 SHOCK,SKI-18.72" ZERO PRO (43")
    SHOCK,SKI-18.72" ZERO PRO (43")
  • 2
    1603-890 RETAINER, SPRING
    RETAINER, SPRING
  • 3
    8047-486 NUT,HEX FLG-NY LOCK 3/8-16 GR F Z & Y
    NUT,HEX FLG-NY LOCK 3/8-16 GR F Z & Y
  • 4
    3604-594 SLEEVE
    SLEEVE
  • 5
    0623-991 WSHR, FLAT ALUM-.390 X 1.125 X .125
    WSHR, FLAT ALUM-.390 X 1.125 X .125
  • 6
    8020-232 SCREW,CAP-HFH 3/8-16 X 3.25 Z & Y
    SCREW,CAP-HFH 3/8-16 X 3.25 Z & Y
  • 7
    2603-493 SPACER, SHOCK MOUNT
    SPACER, SHOCK MOUNT
  • 8
    2703-016 SPRING, COMPRESSION - GREEN
    SPRING, COMPRESSION - GREEN
  • 9
    2703-094 SWAY BAR, 7/16 DIA X 21.21"-PTD BLK
    SWAY BAR, 7/16 DIA X 21.21"-PTD BLK
  • 10
    2603-648 BEARING,SWAY BAR-HIGH TEMP
    BEARING,SWAY BAR-HIGH TEMP
  • 11
    2703-096 ARM,SWAYBAR 3.3"-PTD BLK
    ARM,SWAYBAR 3.3"-PTD BLK
  • 12
    8020-045 SCREW, CAP-HFH 1/4-20 X 1.500 Z & Y
    SCREW, CAP-HFH 1/4-20 X 1.500 Z & Y
  • 13
    8047-366 NUT, LOCK
    NUT, LOCK
  • 14
    2603-649 LINK,SWAY BAR-2.00"
    LINK,SWAY BAR-2.00"
  • 15
    8047-426 NUT, LOCK
    NUT, LOCK
  • 16
    1623-584 BOLT, CARRIAGE
    BOLT, CARRIAGE
