TUNNEL AND REAR BUMPER для Arctic Cat Bearcat Wide Track (USA) - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    0718-785 TUNNEL ASSEMBLY (INC. 3)
    TUNNEL ASSEMBLY (INC. 3)
  • 2
    0606-554 PLATE, SUSPENSION MOUNTING - FRONT
    PLATE, SUSPENSION MOUNTING - FRONT
  • 3
    0716-300 BRACKET, SUSPENSION MOUNTING - LEFT
    BRACKET, SUSPENSION MOUNTING - LEFT
  • 3
    0716-301 BRACKET, SUSPENSION MOUNTING - RIGHT
    BRACKET, SUSPENSION MOUNTING - RIGHT
  • 4
    8060-504 RIVET
    RIVET
  • 5
    0616-869 PAD, TOOLBOX
    PAD, TOOLBOX
  • 6
    3611-470 DECAL, TUNNEL - RIGHT
    DECAL, TUNNEL - RIGHT
  • 6
    3611-471 DECAL, TUNNEL - LEFT
    DECAL, TUNNEL - LEFT
  • 7
    1606-127 SEAL, SEAT RISER
    SEAL, SEAT RISER
  • 8
    0616-866 PLATE, SEAT RISER - RIGHT
    PLATE, SEAT RISER - RIGHT
  • 9
    0616-867 PLATE, SEAT RISER - LEFT
    PLATE, SEAT RISER - LEFT
  • 10
    0604-497 GUIDE, TRACK
    GUIDE, TRACK
  • 11
    0623-268 SCREW, MACHINE
    SCREW, MACHINE
  • 12
    0616-845 BUMPER, REAR
    BUMPER, REAR
  • 13
    8060-484 RIVET
    RIVET
  • 14
    8011-040 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 15
    0623-579 HINGE, SEAT
    HINGE, SEAT
  • 16
    8050-217 WASHER
    WASHER
  • 17
    8040-366 NUT, LOCK
    NUT, LOCK
  • 18
    0606-029 REFLECTOR, REAR - RED
    REFLECTOR, REAR - RED
  • 19
    8017-584 SCREW, MACHINE
    SCREW, MACHINE
  • 20
    0616-884 SNOWFLAP, REVERSE
    SNOWFLAP, REVERSE
  • 21
    0616-864 PLATE, SEAT RISER - FRONT RIGHT
    PLATE, SEAT RISER - FRONT RIGHT
  • 22
    0616-865 PLATE, SEAT RISER - FRONT LEFT
    PLATE, SEAT RISER - FRONT LEFT
  • 23
    0616-842 PLATE, END - TUNNEL
    PLATE, END - TUNNEL
  • 24
    1606-509 INSERT, BUMPER
    INSERT, BUMPER
  • 25
    0616-948 PLATE, SEAT RISER - CENTER
    PLATE, SEAT RISER - CENTER
  • 26
    0616-868 PLATE, SEAT RISER - REAR
    PLATE, SEAT RISER - REAR
  • 27
    0623-269 CLIP, RETAINING
    CLIP, RETAINING
  • 28
    0606-983 PLUG, BODY
    PLUG, BODY
  • 29
    0411-053 DECAL, ''CE''
    DECAL, ''CE''
  • 30
    1606-478 FOOTREST, REAR - RIGHT
    FOOTREST, REAR - RIGHT
  • 30
    1606-479 FOOTREST, REAR - LEFT
    FOOTREST, REAR - LEFT
  • 31
    8041-366 NUT, LOCK
    NUT, LOCK
  • 32
    0623-057 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 33
    0616-952 SEAL, SEAT BASE
    SEAL, SEAT BASE
  • 34
    0616-953 SEAL, SEAT BASE
    SEAL, SEAT BASE
  • 35
    8002-039 SCREW, CAP
    SCREW, CAP
  • 36
    8051-212 WASHER, LOCK
    WASHER, LOCK
  • 37
    8060-704 RIVET
    RIVET
  • 38
    0616-863 BRACKET, HOLD-DOWN - FUEL TANK
    BRACKET, HOLD-DOWN - FUEL TANK
  • 39
    1606-098 LEVER, SEAT LATCH
    LEVER, SEAT LATCH
  • 40
    0616-945 BRACKET, MOUNTING - SEAT LEVER
    BRACKET, MOUNTING - SEAT LEVER
  • 41
    8060-706 RIVET
    RIVET
  • 42
    0623-610 SPRING, LEVER RETURN - RIGHT
    SPRING, LEVER RETURN - RIGHT
  • 43
    0123-397 CLAMP, CABLE
    CLAMP, CABLE
  • 44
    8060-428 RIVET
    RIVET
  • 45
    0123-149 WASHER
    WASHER
  • 46
    0623-184 WASHER
    WASHER
  • 47
    0623-078 DISC, VELCRO
    DISC, VELCRO
  • 48
    0623-582 INSERT
    INSERT
  • 49
    0623-404 CAP, PROTECTOR
    CAP, PROTECTOR
  • 50
    0616-396 CAP, BUMPER - END
    CAP, BUMPER - END
  • 50
    0616-397 CAP, BUMPER - END
    CAP, BUMPER - END
