AIR INTAKE ASSEMBLY для Arctic Cat MUDPRO 1000 H2 INTERNATIONAL - Ver 2 Engine Number 0950T40010060 and Up WHITE [A2010IFW4EOSW] - 2010 года выпуска

  • №
    Артикул
    Название
  • 1
    0413-265 DUCT, AIR INTAKE
    DUCT, AIR INTAKE
  • 2
    0423-019 CLAMP
    CLAMP
  • 3
    0470-583 BOOT, AIR INTAKE
    BOOT, AIR INTAKE
  • 4
    0423-342 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 5
    0430-055 SENSOR, AIR TEMPERATURE (INC. 6)
    SENSOR, AIR TEMPERATURE (INC. 6)
  • 6
    5507-224 ...O-RING
    ...O-RING
  • 7
    0423-716 WING NUT
    WING NUT
  • 8
    0470-832 COVER, AIR INTAKE
    COVER, AIR INTAKE
  • 9
    0470-828 FILTER, AIR
    FILTER, AIR
  • 10
    0470-731 SUPPORT, AIR FILTER
    SUPPORT, AIR FILTER
  • 11
    0570-221 HOUSING, AIR INTAKE
    HOUSING, AIR INTAKE
  • 12
    0406-877 BUMPER
    BUMPER
  • 13
    0470-858 VALVE, DRAIN
    VALVE, DRAIN
  • 14
    0470-638 BOOT, THROTTLE BODY
    BOOT, THROTTLE BODY
  • 15
    0423-066 CLAMP,HOSE-WORM 50MMX9MM (40-60 NORMA)
    CLAMP,HOSE-WORM 50MMX9MM (40-60 NORMA)
  • 16
    0623-028 CLAMP, HOSE
    CLAMP, HOSE
  • 17
    0410-198 HOSE, SEPARATOR TANK
    HOSE, SEPARATOR TANK
  • 18
    0470-718 TANK, SEPARATOR
    TANK, SEPARATOR
  • 19
    0410-196 HOSE, CRANKCASE
    HOSE, CRANKCASE
  • 20
    0410-208 HOSE, CRANKCASE
    HOSE, CRANKCASE
