CYLINDER W/ HEAD ASSY. для Yamaha MAJESTY - 2010 года выпуска
-
№АртикулНазвание
-
15RU-11101-01-00 CYLINDER HEAD ASSYCYLINDER HEAD ASSY
-
25JW-11133-10-00 GUIDE, VALVE 1GUIDE, VALVE 1
-
393440-09141-00 CIRCLIPCIRCLIP
-
43P6-11134-10-00 GUIDE, VALVE 2GUIDE, VALVE 2
-
590105-06026-00 BOLT, FLANGEBOLT, FLANGE
-
690340-12007-00 PLUG, STRAIGHT SCREWPLUG, STRAIGHT SCREW
-
790105-06424-00 BOLT, FLANGEBOLT, FLANGE
-
890430-06014-00 GASKETGASKET
-
995612-08620-00 BOLT, STUDBOLT, STUD
-
10NGK-CR7E0-00-00 PLUG, SPARK (NGK CR7E)PLUG, SPARK (NGK CR7E)
-
115RU-11181-00-00 GASKET, CYLINDER HEAD 1GASKET, CYLINDER HEAD 1
-
1291318-06150-00 BOLTBOLT
-
1390201-06034-00 WASHER, PLATEWASHER, PLATE
-
1490179-10006-00 NUTNUT
-
1590176-10075-00 NUT, CROWNNUT, CROWN
-
1690201-103M4-00 WASHER, PLATEWASHER, PLATE
-
1799530-10014-00 PIN, DOWELPIN, DOWEL
-
185RU-11191-00-00 COVER, CYLINDER HEAD 1COVER, CYLINDER HEAD 1
-
195RU-11193-00-00 GASKET, HEAD COVER 1GASKET, HEAD COVER 1
-
2090464-09017-00 CLAMPCLAMP
-
215RU-11138-00-00 PLUGPLUG
-
225BE-12241-00-00 GUIDE, STOPPER 2GUIDE, STOPPER 2
-
2395022-06030-00 BOLT, FLANGEBOLT, FLANGE
-
2490109-066F0-00 BOLTBOLT
-
254KG-1111G-00-00 RUBBER, MOUNT 1RUBBER, MOUNT 1
-
265RU-11310-21-00 CYLINDERCYLINDER
-
275RU-11351-00-00 GASKET, CYLINDERGASKET, CYLINDER
-
2893210-86509-00 O-RINGO-RING
-
2995022-06030-00 BOLT, FLANGEBOLT, FLANGE
