FOOTREST W/ BRAKE PEDAL для Yamaha RAPTOR 50 - 2007 года выпуска
-
№АртикулНазвание
-
15YF-21639-00-00 DAMPER 2DAMPER 2
-
25YF-27411-00-00 FOOTREST 1FOOTREST 1
-
35YF-27421-00-00 FOOTREST 2FOOTREST 2
-
495817-12020-00 BOLT, FLANGEBOLT, FLANGE
-
55YF-27413-00-00 COVER, FOOTRESTCOVER, FOOTREST
-
690480-18171-00 GROMMETGROMMET
-
75YF-27453-00-00 COVER 1COVER 1
-
85YF-27463-00-00 COVER 2COVER 2
-
990480-14604-00 GROMMETGROMMET
-
1090387-065G0-00 COLLARCOLLAR
-
1197007-06020-00 BOLTBOLT
