INLET REED VALVE для Tohatsu M40C - 2004 года выпуска
-
№АртикулНазвание
-
1345B02010-0 Inlet ManifoldInlet Manifold
-
2345-02104-0 Gasket “A”，Inlet ManifoldGasket “A”，Inlet Manifold
-
'3345-02105-0 Gasket "B", Inlet ManifoldGasket "B", Inlet Manifold
-
4910114-5630 BottBott
-
5345-02100-1 Reed Valve AssyReed Valve Assy
-
6345-02106-0 Plate, Valve SeatPlate, Valve Seat
-
7910121-7620 BoltBolt
-
8921521-7412 ScrewScrew
-
9915321-0655 Stud BoltStud Bolt
-
10915321-0620 Stud BoltStud Bolt
-
11345-02011-0 Gasket, CarburetorGasket, Carburetor
-
12930113-0600 NutNut
-
'13941303-0600 Spring WasherSpring Washer
