SUSPENSION - REAR SWING ARM W/ SHOCK для Suzuki VLR1800T K8 - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    61100-22H00-019 SWINGINGARM, REAR (BLACK)
    SWINGINGARM, REAR (BLACK)
  • 2
    09103-08071 BOLT, RR SWGARM PIVOT CLAMP
    BOLT, RR SWGARM PIVOT CLAMP
  • 3
    09263-25059 BEARING, RR SWGARM PIVOT
    BEARING, RR SWGARM PIVOT
  • 4
    61251-31E00 SPACER, RR SWGARM PIVOT
    SPACER, RR SWGARM PIVOT
  • 5
    61280-48G01 SPACER, RR SWGARM
    SPACER, RR SWGARM
  • 6
    61211-48G00 SHAFT, RR SWGARM PIVOT
    SHAFT, RR SWGARM PIVOT
  • 7
    61372-48G00 BOOT, PROPELLER SHAFT
    BOOT, PROPELLER SHAFT
  • 8
    61126-22H00-019 COVER, RR SWGARM, L (BLACK)
    COVER, RR SWGARM, L (BLACK)
  • 9
    61127-41F10 BOLT, RR SWGARM COVER R
    BOLT, RR SWGARM COVER R
  • 10
    09139-06140 BOLT, RR SWGARM COVER FR
    BOLT, RR SWGARM COVER FR
  • 11
    09320-22003 CUSHION, RR SWGARM COVER
    CUSHION, RR SWGARM COVER
  • 12
    41899-42F10 CAP, RR SWGARM COVER
    CAP, RR SWGARM COVER
