HOOD - FOAM/FOIL/SCREENS для Polaris SPORT TOURING (S04NU5BS) - 2004 года выпуска`
-
№АртикулНазвание
-
15812424 FOIL, LOUVER (RIGHT)FOIL, LOUVER (RIGHT)
-
25812107 FOIL (RIGHT)FOIL (RIGHT)
-
35812106 FOIL (RIGHT)FOIL (RIGHT)
-
45810345 FOIL, TAPEFOIL, TAPE
-
55812270 FOAM (REAR/LEFT)FOAM (REAR/LEFT)
-
65812286 FOAM (FRONT/LEFT)FOAM (FRONT/LEFT)
-
75811830 FOAM (CENTER)FOAM (CENTER)
Все узлы модели:
- BRAKE ASSEMBLY
- BUMPER/HITCH FLAP
- CARBURETOR ASSEMBLY
- CARGO BOX W/ TAILLIGHT ASSY
- CHAINCASE ASSEMBLY
- CLUTCH - DRIVE
- CLUTCH - DRIVEN
- CONSOLE
- CRANKCASE ASSEMBLY
- CYLINDER ASSEMBLY
- DECALS
- DRIVE TRAIN ASSEMBLY W/ DRIVE BELT
- ELECTRICAL - MAGNETO ASSEMBLY W/ COIL
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FRAME - CHASSIS
- FUEL PUMP
- FUEL TANK
- HANDLEBAR ASSEMBLY W/ CONTROLS
- • HOOD - FOAM/FOIL/SCREENS
- HOOD ASSEMBLY W/ HEADLIGHT
- NOSEPAN ASSEMBLY #1
- NOSEPAN ASSEMBLY #2
- OIL PUMP ASSEMBLY
- OIL TANK W/ AIR BOX ASSEMBLY
- PISTON AND CRANKSHAFT
- RAIL ASSEMBLY W/ IDLER WHEELS
- SEAT W/ TAILLIGHT
- STARTER - RECOIL ASSEMBLY W/ BLOWER HOUSING
- STEERING ASSEMBLY #1
- STEERING ASSEMBLY #2
- SUSPENSION - FRONT TORQUE ARM ASSEMBLY
- SUSPENSION - FRONT W/ SKI
- SUSPENSION - REAR SHOCK TRACK
- SUSPENSION - REAR TORQUE ARM ASSEMBLY
- TOOL KIT
- WINDSHIELD/GUAGES/HOOD RETAINER
