FUEL TANK для Polaris 600 CLASSIC (S04ND6ES) - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    7080804 CABLE TIE RELEASABLE (5 1/2")
    CABLE TIE RELEASABLE (5 1/2")
  • 2
    2511195-070 CAP, FUEL ASSY (BLACK)
    CAP, FUEL ASSY (BLACK)
  • 2
    5810512 GASKET
    GASKET
  • 3
    7052095 FITTING (90 DEG)
    FITTING (90 DEG)
  • 4
    8450061-600 LINE, FUEL
    LINE, FUEL
  • 5
    7542122 NUT NYLOK
    NUT NYLOK
  • 6
    7555960 WASHER, FLAT
    WASHER, FLAT
  • 7
    7670021 NUT, SPEED
    NUT, SPEED
  • 8
    7512193 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 9
    5810947 FOAM, SEAL
    FOAM, SEAL
  • 10
    7052215 PICK UP, FUEL WITH MESH
    PICK UP, FUEL WITH MESH
  • 11
    7080768 RING, COMPRESSION
    RING, COMPRESSION
  • 12
    8350020-160 FUEL, LINE ETHER
    FUEL, LINE ETHER
  • 13
    5432981 GROMMET
    GROMMET
  • 14
    7052269 FITTING STRAIGHT
    FITTING STRAIGHT
  • 15
    2520289 FUEL TANK, WITH SEND ASSY (5/16) (INCL. 3-10)
    FUEL TANK, WITH SEND ASSY (5/16) (INCL. 3-10)
  • 16
    2410352 SENDER FUEL, 12 GAL (LEFT)
    SENDER FUEL, 12 GAL (LEFT)
  • 17
    2410456 PKG HEADWR SENDING UNIT
    PKG HEADWR SENDING UNIT
  • 18
    8350017-600 FUEL LINE ETHER (RED)
    FUEL LINE ETHER (RED)
  • 19
    7080003 CLAMP, HOSE
    CLAMP, HOSE
  • 20
    1253424 VALVE, FUEL PLASTIC ASSY
    VALVE, FUEL PLASTIC ASSY
  • 21
    8360052-25 TUBING CONVOLUTED (.50ID/25CM)
    TUBING CONVOLUTED (.50ID/25CM)
  • 22
    2520275 PUMP FUEL (5/16 IN/OUT, MIK)
    PUMP FUEL (5/16 IN/OUT, MIK)
  • 23
    8450040-600 FUEL LINE (1/4 ID, 600 CM)
    FUEL LINE (1/4 ID, 600 CM)
